575624 Festo Directional Control Valves

Product Details

• Material of screws
  Steel, nickel-plated
• Standard nominal flow rate
  1600 l/min
• Sealing principle
  Soft
• Flow direction
  Reversible
• Max. negative test pulse on 1 signal
  3600 µs
• Vibration resistance
  Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
• Shock resistance
  Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
• Venting hole connection
  Not ducted
• Pneumatic connection 4
  G3/8
• Note on materials
  RoHS-compliant
• Valve function
  5/3, pressurized
• Actuation type
  Electrical
• Pneumatic working port
  G3/8
• Certification
  c UL us - Recognized (OL)
• Type code
  VUVS
• Mounting position
  Any
• Symbol
  00991031
• C value
  6.6 l/sbar
• Changeover time
  31 ms
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
Pilot exhaust air port 82
M5
Pilot air port 14
G1/8
Pneumatic connection 1
G3/8
Piston slide material
Wrought aluminum alloy
Valve size
31 mm
Reset method
Mechanical spring
Nominal width
8.1 mm
Pilot air supply port
External
Pilot pressure
2.5 bar ... 10 bar
Max. positive test pulse with 0 signal
2000 µs
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Ambient temperature
-10 °C ... 60 °C
Pilot exhaust air port 84
M5
Pneumatic connection 5
G3/8
Housing material
Die-cast aluminum Painted
Lap
Overlap
Operating pressure
-0.9 bar ... 10 bar
Exhaust air function
With flow control option
Type of control
Pilot-controlled
Switching time off
75 ms
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Pilot medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Product weight
461 g
Pilot air port 12
G1/8
Seals material
HNBR NBR
Maritime classification
See certificate
Design
Piston gate valve
Manual override
Detenting Non-detenting
b-value
0.4
Certificate issuing authority
DNVGL-TAA000011J
On switching time
18 ms
Temperature of medium
-10 °C ... 60 °C
Type of mounting
Optionally: With through-hole
Pneumatic connection 2
G3/8
Pneumatic connection 3
G3/8
