567773 Festo Pneumatic Fittings

567773 on Powermatic Associates
Festo

Part#:567773

Alt. Part#:QB-1/8-3/8-U

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

8 in stock

Mar 15, 2025

Product description

push-in fitting QB-1/8-3/8-U male thread with external hexagon. Size: Standard, Nominal size: 0,189 ", Type of seal on screw-in stud: coating, Assembly position: Any, Design structure: Push/pull principle

Product Details

  • Type code
    QB
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Housing material
    Brass, nickel-plated
  • Nominal width
    4.801 mm
  • Design
    Push-pull principle
  • Temperature-dependent operating pressure
    -0.951 bar ... 9.997 bar
  • Product weight
    21.404 g
  • Pneumatic connection 1
    External thread NPT1/8-27
  • Material of tube retaining claw
    High-alloy stainless steel
  • Size
    Standard
  • Mounting position
    Any
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Max. tightening torque
    7 Nm
  • Releasing ring color
    Gray
  • Material of threaded seal
    PTFE
  • Type of seal on screwed trunnion
    Coating
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant
  • Material of tubing seal
    NBR
  • Operating pressure for entire temperature range
    -0.951 bar ... 9.997 bar
  • Ambient temperature
    0 °C ... 60 °C
  • Pneumatic connection 2
    for pneumatic tubing outside diameter 3/8"
  • Releasing ring material
    POM

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

567773 Related Documents

567773 DataSheet.pdf

Manufacturer warranty
