190771 Festo Pneumatic Fittings
Part#:190771
Alt. Part#:QSLV2-1/4-3/8-U
Manufacturer:Festo
Category:Pneumatic Fittings
Product Lifecycle:Active
Mar 15, 2025
Product description
multiple distributor QSLV2-1/4-3/8-U 2-fold, 360° orientable. Size: Standard, Nominal size: 5,1 mm, Type of seal on screw-in stud: coating, Assembly position: Any, Design structure: Push/pull principle
Product Details
- Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-]
- Ambient temperature -10 °C ... 60 °C
- No. of outlets 2
- Pneumatic connection 2 for pneumatic tubing outside diameter 3/8"
- Note on materials RoHS-compliant
- Nominal width 5.1 mm
- Operating pressure for entire temperature range -0.95 bar ... 10 bar
- Design Push-pull principle
- Max. tightening torque 14 Nm
- Pneumatic connection 1 external thread 1/4 NPT
- Housing material PBT
- Material of tube retaining claw High-alloy stainless steel
- Size Standard
- Mounting position Any
- Maritime classification See certificate
- Type code QSLV2
- Pack size 1
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- No. of supply lines 1
- Releasing ring material POM
- Material of screwed trunnion Brass, nickel-plated
- Type of seal on screwed trunnion Coating
- Information on operating and pilot media Operation with oil lubrication possible
- Product weight 81 g
- Releasing ring color Gray
- Material of tubing seal NBR
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
190771 Related Documents
Manufacturer warranty
190771 Festo
Get a quick Quote!
Request a quote, and we will send you price within minutes.
Stock:
Select Qty:
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 190771 with other products
Operating medium
Ambient temperature
No. of outlets
Pneumatic connection 2
Note on materials
Nominal width
Operating pressure for en...
Design
Max. tightening torque
Pneumatic connection 1
Housing material
Material of tube retainin...
Size
Mounting position
Maritime classification
Type code
Pack size
Corrosion resistance clas...
No. of supply lines
Releasing ring material
Material of screwed trunn...
Type of seal on screwed t...
Information on operating ...
Product weight
Releasing ring color
Material of tubing seal
Temperature-dependent ope...
Selected product
190771
Festo
multiple distributor QSLV2-1/4-3/8-U 2-fold, 360° orientable. Size: Standard, Nominal size: 5,1 mm, ...
Operating mediumCompressed air as per ISO 85...
Ambient temperature-10 °C ... 60 °C
No. of outlets2
Pneumatic connection 2for pneumatic tubing outside...
Note on materialsRoHS-compliant
Nominal width5.1 mm
Operating pressure for entire temperature range-0.95 bar ... 10 bar
DesignPush-pull principle
Max. tightening torque14 Nm
Pneumatic connection 1external thread 1/4 NPT
Housing materialPBT
Material of tube retaining clawHigh-alloy stainless steel
SizeStandard
Mounting positionAny
Maritime classificationSee certificate
Type codeQSLV2
Pack size1
Corrosion resistance class (CRC)1 - Low corrosion stress
No. of supply lines1
Releasing ring materialPOM
Material of screwed trunnionBrass, nickel-plated
Type of seal on screwed trunnionCoating
Information on operating and pilot mediaOperation with oil lubricati...
Product weight81 g
Releasing ring colorGray
Material of tubing sealNBR
Temperature-dependent operating pressure-
153145
Festo
push-in Y-fitting QSY-3/8-10 360° orientable, male thread with external hexagon. Size: Standard, Nom...
Operating mediumCompressed air as per ISO 85...
Ambient temperature-10 °C ... 80 °C
No. of outlets2
Pneumatic connection 2for pneumatic tubing outside...
Note on materialsRoHS-compliant
Nominal width7.4 mm
Operating pressure for entire temperature range-0.95 bar ... 6 bar
DesignPush-pull principle
Max. tightening torque-
Pneumatic connection 1External thread R3/8
Housing materialPBT
Material of tube retaining clawHigh-alloy stainless steel
SizeStandard
Mounting positionAny
Maritime classificationSee certificate
Type codeQSY
Pack size10
Corrosion resistance class (CRC)1 - Low corrosion stress
No. of supply lines1
Releasing ring materialPOM
Material of screwed trunnion-
Type of seal on screwed trunnionCoating
Information on operating and pilot mediaOperation with oil lubricati...
Product weight43 g
Releasing ring colorBlue
Material of tubing sealNBR
Temperature-dependent operating pressure-0.95 bar ... 14 bar
183744
Festo
push-in fitting QS-1/4-3/8-I-U-M male thread with internal hexagon socket. Size: Standard, Nominal s...
Operating mediumCompressed air as per ISO 85...
Ambient temperature0 °C ... 60 °C
No. of outlets-
Pneumatic connection 2for pneumatic tubing outside...
Note on materialsRoHS-compliant
Nominal width7.29 mm
Operating pressure for entire temperature range-0.95 bar ... 9.997 bar
DesignPush-pull principle
Max. tightening torque-
Pneumatic connection 1External thread R1/4
Housing materialBrass Nickel-plated
Material of tube retaining clawHigh-alloy stainless steel
SizeStandard
Mounting positionAny
Maritime classificationSee certificate
Type codeQS
Pack size1
Corrosion resistance class (CRC)1 - Low corrosion stress
No. of supply lines-
Releasing ring materialPOM
Material of screwed trunnion-
Type of seal on screwed trunnionCoating
Information on operating and pilot mediaOperation with oil lubricati...
Product weight22 g
Releasing ring colorGray
Material of tubing sealNBR
Temperature-dependent operating pressure-
About the manufacturer
Powermatic Associates is an authorized Festo distributor, proudly offering a wide array of Festo's innovative industrial automation products and solutions. Festo is a globally recognized leader in automation technology and pneumatic solutions, renowned for their commitment to quality, efficiency, and sustainability. With a vast portfolio ranging from actuators, valves, sensors, and connectors to electric drives and complete automation systems, Festo ensures that industries can achieve seamless operations and enhanced productivity. As specialists in motion and control technologies, Powermatic Associates supplies Festo's advanced pneumatics and electromechanical systems, designed to meet the rigorous demands of modern manufacturing environments. Festo's pneumatic cylinders and actuators are engineered for precision and reliability, providing optimal performance in a variety of applications, from simple handling tasks to complex automation processes. Festo's cutting-edge sensors and control units further complement these systems by delivering accurate data and enabling sophisticated process control, which are essential for smart factory initiatives. Moreover, Festo excels in modular automation solutions, allowing businesses to customize systems tailored specifically to their operational needs. Their energy-efficient pneumatic components and electric automation solutions are designed to reduce energy consumption and contribute to sustainable manufacturing practices. By integrating Festo’s products into their facilities, customers can streamline production processes, minimize downtime, and elevate overall operational efficiency. Powermatic Associates complements Festo's product range with our extensive value-added services, including expert engineering support and customized automation solutions. Our partnership with Festo allows us to provide superior technical assistance and rapid delivery from our well-stocked inventory. Whether you need precise fluid control, reliable actuation, or comprehensive system integration, Powermatic Associates and Festo together offer unparalleled service and solutions. Trust in our collaboration to harness the latest advancements in automation technology, ensuring your projects remain on track and your business achieves maximum profitability. Through this strategic partnership, Powermatic Associates and Festo empower industries to embrace innovation and maintain a competitive edge in the fast-evolving industrial landscape, driving forward efficiency, productivity, and sustainability.
About the Product Category
Air fittings, also referred to as pneumatic fittings or connectors, are crucial components of pneumatic systems. They ensure safe and airtight connections between various pneumatic elements like air hoses, tubes, valves, and cylinders.
