186117 Festo Pneumatic Fittings

186117 on Powermatic Associates
Festo

Part#:186117

Manufacturer:Festo

Category:Pneumatic Fittings

Alt. Part#:QSL-G1/8-6

Product Lifecycle:Active

In-stock parts: 10

Dec 21, 2024

push-in L-fitting QSL-G1/8-6 360° orientable, male thread with external hexagon. Size: Standard, Nominal size: 4,2 mm, Type of seal on screw-in stud: Sealing ring, Assembly position: Any, Container size: 10

About the manufacturer: Festo is one of the manufacturers that offers Pneumatic Fittings that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 186117 Festo price in the box on the right side or send a quick quote.

Product Details

  • Maritime classification
    See certificate
  • Mounting position
    Any
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Pneumatic connection 1
    External thread G1/8
  • Material of tube retaining claw
    High-alloy stainless steel
  • Size
    Standard
  • Nominal width
    4.2 mm
  • Pack size
    10
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
  • Nominal tightening torque
    7 Nm
  • Pneumatic connection 2
    for pneumatic tubing outside diameter 6 mm
  • Housing material
    PBT
  • Type of seal on screwed trunnion
    Sealing ring
  • Ambient temperature
    -10 °C ... 80 °C
  • Note on materials
    RoHS-compliant
  • Operating pressure for entire temperature range
    -0.95 bar ... 6 bar
  • Temperature-dependent operating pressure
    -0.95 bar ... 14 bar
  • Releasing ring color
    Blue
  • Material of tubing seal
    NBR
  • Type code
    QSL
  • Design
    Push-pull principle
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Tolerance for nominal tightening torque
    ± 20%
  • Product weight
    14 g
  • Releasing ring material
    POM

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents 186117 Specs

186117 186117 DataSheet.pdf

This item can ship within 24h!

Manufacturer warranty

$3.69

Stock:

10

Select Qty:

$3.69

$3.69 each

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
