186120 Festo Pneumatic Fittings

186120 on Powermatic Associates
Festo

Part#:186120

Alt. Part#:QSL-G1/4-8

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

6 in stock

Apr 12, 2025

Product description

push-in L-fitting QSL-G1/4-8 360° orientable, male thread with external hexagon. Size: Standard, Nominal size: 6,7 mm, Type of seal on screw-in stud: Sealing ring, Assembly position: Any, Container size: 10

Product Details

  • Maritime classification
    See certificate
  • Mounting position
    Any
  • Nominal tightening torque
    9 Nm
  • Pneumatic connection 2
    for pneumatic tubing outside diameter 8 mm
  • Nominal width
    6.7 mm
  • Operating pressure for entire temperature range
    -0.95 bar ... 6 bar
  • Product weight
    23 g
  • Tolerance for nominal tightening torque
    ± 20%
  • Releasing ring material
    POM
  • Size
    Standard
  • Type of seal on screwed trunnion
    Sealing ring
  • Temperature-dependent operating pressure
    -0.95 bar ... 14 bar
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
  • Note on materials
    RoHS-compliant
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Ambient temperature
    -10 °C ... 80 °C
  • Housing material
    PBT
  • Material of tubing seal
    NBR
  • Type code
    QSL
  • Pack size
    10
  • Design
    Push-pull principle
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Pneumatic connection 1
    External thread G1/4
  • Releasing ring color
    Blue
  • Material of tube retaining claw
    High-alloy stainless steel

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
