170863 Festo Pneumatic Actuators
Part#:170863
Alt. Part#:DFM-32-200-P-A-GF
Manufacturer:Festo
Category:Pneumatic Actuators
Product Lifecycle:Active
Product description
guided drive DFM-32-200-P-A-GF With integrated guide. Centre of gravity distance from working load to yoke plate: 50 mm, Stroke: 200 mm, Piston diameter: 32 mm, Operating mode of drive unit: Yoke, Cushioning: P: Flexible cushioning rings/plates at both en
Product Details
- Max. permissible torque load Mx as a function of the stroke 5 Nm
- Drive unit operating mode Yoke
- Guide Sliding guide
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Ambient temperature -20 °C ... 80 °C
- Moving mass 2232 g
- Cover material Wrought aluminum alloy
- Stroke 200 mm
- Cushioning Elastic cushioning rings/pads at both ends
- Operating pressure 0.15 MPa ... 1 MPa
- Symbol 00991737
- Max. payload as a function of the stroke at defined distance xs 127 N
- Alternative connections See product drawing
- Piston rod material High-alloy stainless steel
- Distance of centre of gravity of payload to yoke plate xs 50 mm
- Piston diameter 32 mm
- Design Guide
- Max. speed 0.8 m/s
- Impact energy in the end positions 0.4 J
- Product weight 4781 g
- Pneumatic connection G1/8
- Type code DFM
- Position sensing For proximity sensor
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Theoretical force at 6 bar, advancing 482 N
- Seals material NBR
- Mounting position Any
- Mode of operation Double-acting
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Theoretical force at 6 bar, retracting 415 N
- Note on materials RoHS-compliant
- Housing material Wrought aluminum alloy
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
