170860 Festo Pneumatic Actuators

Name: 170860
Brand: Festo

Part#:170860

Alt. Part#:DFM-32-100-P-A-GF

Manufacturer:Festo

Category:Pneumatic Actuators

Product Lifecycle:Active

Only 2 left in stock. Order Now!

Apr 1, 2025

Product description

guided drive DFM-32-100-P-A-GF With integrated guide. Centre of gravity distance from working load to yoke plate: 50 mm, Stroke: 100 mm, Piston diameter: 32 mm, Operating mode of drive unit: Yoke, Cushioning: P: Flexible cushioning rings/plates at both en

Product Details

Distance of centre of gravity of payload to yoke plate xs
50 mm
Piston diameter
32 mm
Mounting position
Any
Symbol
00991737
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Moving mass
1564 g
Cover material
Wrought aluminum alloy
Type code
DFM
Operating pressure
0.15 MPa ... 1 MPa
Max. payload as a function of the stroke at defined distance xs
150 N
Alternative connections
See product drawing
Max. permissible torque load Mx as a function of the stroke
5.8 Nm
Drive unit operating mode
Yoke
Design
Guide
Max. speed
0.8 m/s
Ambient temperature
-20 °C ... 80 °C
Impact energy in the end positions
0.4 J
Theoretical force at 6 bar, advancing
482 N
Pneumatic connection
G1/8

Seals material

NBR

Stroke

100 mm

Cushioning

Elastic cushioning rings/pads at both ends

Mode of operation

Double-acting

Product weight

3111 g

Piston rod material

High-alloy stainless steel

Guide

Sliding guide

Position sensing

For proximity sensor

Corrosion resistance class (CRC)

1 - Low corrosion stress

Theoretical force at 6 bar, retracting

415 N

Note on materials

RoHS-compliant

Housing material

Wrought aluminum alloy

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
