161756 Festo Proximity Sensors

Product Details

• Symbol
  00991624
• Switching element function
  N/O contact
• Electrical connection 1, connection type
  Cable
• Measuring principle
  Magnetic reed
• Switching output
  Contact-based, bipolar
• Max. output current
  500 mA
• Overload protection
  Not available
• Cable length
  2.5 m
• Electrical connection 1, connection technology
  Open end
• Ambient temperature
  -40 °C ... 120 °C
• On time
  ≤ 0.5 ms
• Min. switching capacity AC
  10 VA
• Voltage drop
  ≤ 0 V
• Operating voltage range AC
  0 V ... 30 V
• Connection outlet orientation
  Longitudinal
• Type of mounting
  Clamped in T slot Can be inserted in slot lengthwise
• Product weight
  50 g
• Surge resistance
  0.8 kV
• Type code
  SME
• Design
  for T-slot
Conforms to standard
EN 60947-5-2
Switch-off time
≤ 0.03 ms
Max. switching capacity DC
10 W
Reverse polarity protection
no
Tightening torque
0.2 Nm
Degree of protection
IP67
Electrical connection 1, number of pins/wires
2
Note on materials
Free of copper and PTFE RoHS-compliant
Reproducibility of switching value
+/- 0.1 mm
Ambient temperature with flexible cable installation
-5 °C ... 120 °C
Contamination level
3
Max. switching frequency
800 Hz
Short-circuit protection
no
DC operating voltage range
0 V ... 30 V
Material of cable sheath
TPE-S
Housing material
Epoxy resin High-alloy stainless steel
Insulation voltage
50 V
