SP150WA120 on Powermatic Associates
Banner

Part#:SP150WA120

Manufacturer:Banner

Category:Electronic Components

Product Lifecycle:Active

Product description

Banner Engineering SP150WA120, part of the EZ-LIGHT series, is a traffic light designed with a 1-tier 1-color white LED illumination. This product features a polycarbonate (PC) base and a black housing, equipped with a screw-clamp terminal connection for secure installation. It operates on a supply voltage range of 85Vac-130Vac (100Vac / 110Vac / 120Vac nominal) for AC and 75Vdc-120Vdc (110Vdc nominal) for DC, making it versatile for various power setups. The SP150WA120 can be mounted on surfaces or walls and is designed to function within an ambient air temperature range of -40°C to +50°C. It boasts an IP67 degree of protection, ensuring durability against dust and water ingress. The unit consumes 16mA of current and includes 1 x digital input (85-130Vac / 75-120Vdc) for color control, enhancing its functionality as an LED traffic signal light.

Product Details

  • Application: Traffic Light
    Yes
  • Indication Intensity
    High Brightness & Daylight Visible
  • Max Op. Temperature (°C)
    50
  • Physical Dimensions (LxWxH or DxH mm)
    93.1 x 80.9 x 91.6
  • Connection
    Terminal
  • Color Technology
    Standard LED
  • Primary Housing Material
    Polycarbonate
  • Pro-Editor Compatible (Discrete)
    No
  • Wireless
    No
  • Modbus RTU
    No
  • IO Link
    No
  • Feature: Quick Disconnect
    No
  • Multi-Color Device
    Single Color On
  • Feature: Chemical Resistant
    No
  • Feature: Hazardous Area
    No
  • Feature: Audible
    No
  • Max Input Response Time (ms)
    10
  • Input Type
    AC
  • Min Op. Temperature (°C)
    -40
  • Environmental Rating
    IP67
  • Lumens Color 1
    20.0
  • Number of Input Pins/Conductors
    2
  • Supply Voltage
    85-130 V ac/75-120 V dc
  • Color 1 - Wavelength/Color Temp/Coordinates
    6000K
  • Max Current Color (mA)
    16
  • Color Option 1
    White
  • Animation Option 1
    Solid On
  • Housing Style
    Flat Mount - Signal Light
  • Product Size (mm)
    Other
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Number of Colors / Segments
    1
  • Indication
    Yes
  • Mounting Thread
    No Thread
  • Power Source
    DC or AC
  • Power
    DC or AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
