PN18-6F-C Panduit Electronic Components

Product Details

• PN18-6F-C
  7.6
• Product Type
  Loose Piece Forks
• Overall Width (mm)
  7.6
• For Use With
  CT-100, CT-160, CT-260
• Part Features
  Fork design provides for fast and easy installation, without the need to remove fastener. Metal insulation grip sleeve crimps to wire insulation, providing protection to the crimp joint during high vibration applications. Internal barrel serrations assure
• Packaging Type
  Bottle
• Tongue Width (mm)
  7.6
• Tongue Width (In.)
  0.3
• Tongue Thickness (mm)
  0.8
• Tongue Thickness (In.)
  0.03
• Sub Brand
  Pan-Term®
• Tongue Length (mm)
  9.9
• Tongue Length (In.)
  0.39
• Overall Width (In.)
  0.3
• Overall Length (mm)
  19.8
• Stud Hole Size (mm)
  3.5
• Overall Length (In.)
  0.78
• Minimum Wire Insulation Diameter (mm)
  2
• Stud Hole Size (In.)
  1/7
• Minimum Wire Insulation Diameter (In.)
  0.08
Seam Type
Butted
Maximum Operating Temperature (°F)
221
Maximum Wire Insulation Diameter (mm)
3.7
Maximum Wire Insulation Diameter (In.)
0.15
Maximum Operating Temperature (°C)
105
Insulation Diameter (mm)
3.7
Insulation Diameter (In.)
0.15
Flammability Rating
UL 587-H
Barrel Length (mm)
9.9
Barrel Length (In.)
0.39
Barrel Type
Grip Sleeve
Color Code
Red
Finish/Coating
Tin-Plated
Base Material
Copper
Maximum Voltage (kV)
0.6
Maximum Voltage (V)
600
Standards Met
UL Listed 587H E52164; CSA Certified LR31212
Wire Strip Length (mm)
5.5
Maximum Metric Conductor Size (mm²)
1
Wire Strip Length (In.)
0.22
Stud Size
#6
Minimum Metric Conductor Size (mm²)
0.5
Minimum Copper Conductor Size (AWG)
#22
Minimum Copper Conductor Size (AWG STR)
#22
Minimum Copper Conductor Size (AWG SOL)
#22
Minimum Wire Size (AWG)
#22
Maximum Wire Size (AWG)
#18
Maximum Copper Conductor Size (AWG STR)
#18
Maximum Copper Conductor Size (AWG)
#18
Insulation Material
Nylon
Maximum Copper Conductor Size (AWG SOL)
#18
Insulation Type
Nylon
Fork Type
Standard

Related documents PN18-6F-C Specs
