Part#:SP150BA120

Manufacturer:Banner

Category:Electronic Components

Product Lifecycle:Active

Product description

Banner Engineering SP150BA120, part of the EZ-LIGHT series, is a traffic light designed with a 1-tier 1-color blue LED illumination. This product features a polycarbonate (PC) base and a black housing, equipped with a screw-clamp terminal connection for secure installation. It operates on a supply voltage range of 85Vac-130Vac (100Vac / 110Vac / 120Vac nominal) for AC and 75Vdc-120Vdc (110Vdc nominal) for DC, making it versatile for various power setups. The SP150BA120 can be mounted on surfaces or walls and is designed to function within an ambient air temperature range of -40°C to +50°C. It boasts an IP67 degree of protection, ensuring durability against dust and water ingress. The traffic light has a current consumption of 16mA and includes 1 x digital input (85-130Vac / 75-120Vdc) for color control, enhancing its functionality as an LED traffic signal light.

Product Details

  • Pro-Editor Compatible (Discrete)
    No
  • Wireless
    No
  • Modbus RTU
    No
  • IO Link
    No
  • Feature: Quick Disconnect
    No
  • Application: Traffic Light
    Yes
  • Indication Intensity
    High Brightness & Daylight Visible
  • Multi-Color Device
    Single Color On
  • Feature: Chemical Resistant
    No
  • Feature: Audible
    No
  • Min Op. Temperature (°C)
    -40
  • Feature: Hazardous Area
    No
  • Environmental Rating
    IP67
  • Max Op. Temperature (°C)
    50
  • Input Type
    AC
  • Physical Dimensions (LxWxH or DxH mm)
    93.1 x 80.9 x 91.6
  • Max Input Response Time (ms)
    10
  • Supply Voltage
    85-130 V ac/75-120 V dc
  • Max Current Color (mA)
    16
  • Number of Input Pins/Conductors
    2
  • Color 1 - Wavelength/Color Temp/Coordinates
    470 nm
  • Lumens Color 1
    12.0
  • Connection
    Terminal
  • Color Option 1
    Blue
  • Primary Housing Material
    Polycarbonate
  • Housing Style
    Flat Mount - Signal Light
  • Color Technology
    Standard LED
  • Product Size (mm)
    Other
  • Mounting Thread
    No Thread
  • Number of Colors / Segments
    1
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Indication
    Yes
  • Power Source
    DC or AC
  • Power
    DC or AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

SP150BA120 Related Documents

SP150 NO CABLE-1630952557932.stpSP150 NO CABLE-1630952557930.pdfSP Series Signal Light -- Datasheet-1630952557927.pdf
