Q240RA-EU-AF2Q Banner Optical Sensors

Name: Q240RA-EU-AF2Q
Brand: Banner
Price: 2641 USD
Availability: BackOrder

Part#:Q240RA-EU-AF2Q

Alt. Part#:92481

Manufacturer:Banner

Category:Optical Sensors

Product Lifecycle:Active

Product description

R-GAGE Series; 173 mm x 158 mm Rectangular Housing; Range: 1.0-40 m; Input: 10-30 V dc; M12 Integral QD; Two Bipolar Outputs; EU Frequency

Product Details

Weight
1065.9412 g
Country Of Origin
US
1-wire Serial Interface
No
IO Link
No
Cert: European
Yes
Profibus
No
Wireless
No
SSI
No
RS-485
No
RS-422
No
RS-232
No
Common Ethernet Protocol
No
PROFINET
No
Power/Current Consumption (exclusive of load)
< 85 mA
Supply Protection Circuitry
Protected against reverse polarity and transient overvoltages
Minimum Response Time (ms)
15
Feature: Chemical Resistant
No
Feature: Timing (Hold/Delay)
No
Discrete (Switched) Outputs
2 NPN/PNP Configurable
Min Operating Temperature (°C)
-40

Max Operating Temperature (°C)

Output Protection

Protected against short circuit

Max Discrete (Switched) Output (mA)

150

IP Rating

IP67

Vibration

10 Hz to 55 Hz 0.5 mm p-p amplitude per IEC 60068-2-6

Number of Pins

Adjustments

Dip Switch

Mechanical Shock

30G 11 ms duration, half sine wave per IEC 60068-2-27

Quick Disconnect Type

M12 (Euro)

Minimum Sensing Distance (mm)

1000

Max Sensing Distance (mm)

40000

Input/Output

Discrete

Delay at Power-up (ms)

2000

Power Supply

12-30 V dc

Connection

Integral QD

Radar Beam Pattern (H x V °)

11 x 13

Indicator

LED(s)

Primary Housing Material

Polycarbonate

Sensing Mode (General)

Proximity

Power

Operating Frequency

24 GHz

Max Measurement Range

>20 m - <=50 m

Sensing Beam

Radar

Device Type

Sensor

PC Configurable

Sensing Mode (Detailed)

Time of Flight

Housing Style

Rectangular

Main function

Sensor (Radar)

Sensing distance

1...40m

Digital outputs

2 x digital outputs (PNP/NPN transistors)

Product series / family name

R-GAGE series

Connection type

Pre-equipped with 5-pin Euro-style M12 connector

Sub-range name

Q240R

Design

time-of-flight system Europe / UK / Australia / New Zealand Telecom-approved

Primary brand

Banner Engineering

Functions

Narrow-beam adjustable-field radar sensor green LED (power ON) yellow LED (output state)

Degree of protection

IP67

Emission frequency

24.050GHz...24.250GHz (ISM band)

Supply voltage (DC)

12Vdc-30Vdc (24Vdc nom.)

Shape

Rectangular

Material

polycarbonate housing

Order code / Manufacturer SKU

92481

Operating mode

NO (Normally Open) NC (Normally Closed)

Protection functions

Reverse polarity Short-circuit

Equivalent to

Q240RAEUAF2Q

Compliant with standard(s)

cULus CE

Ambient air temperature for operation

-40...+65 °C

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of Q240RA-EU-AF2Q on Powermatic Associates is $2,641.00. Order now.

About the product

Banner Engineering Q240RA-EU-AF2Q is a narrow-beam adjustable-field radar sensor designed for a variety of applications. It operates within an ambient air temperature range of -40 to +65°C and features a time-of-flight system that is approved for use in Europe, the UK, Australia, and New Zealand. This sensor is equipped with a 5-pin Euro-style M12 connector for easy installation. As part of the Q240R series, it offers an IP67 degree of protection, making it suitable for harsh environments. The sensor operates on a supply voltage of 12Vdc to 30Vdc, with a nominal voltage of 24Vdc. It has a rectangular shape and is constructed with a polycarbonate (PC) housing for durability. The Q240RA-EU-AF2Q operates at a frequency range of 24.050GHz to 24.250GHz within the ISM band, ensuring reliable transmission. It is capable of sensing distances from 1 to 40 meters and offers both Normally Open (NO) and Normally Closed (NC) operating modes. Additionally, it features two digital outputs (PNP/NPN transistor) and is equipped with protection functions against reverse polarity and short-circuit incidents.
