Q12RB6FF15Q Banner Proximity Sensors

Banner Q12RB6FF15Q WORLD-BEAM Q12 Series: Fixed-Field; Range: 15 mm; Input: 10-30 V dc; Output: DO (Dark Operate) Bipolar: 1 NPN; 1 PNP; 150 mm (6 in) M8 Pigtail QD
Banner

Part#:Q12RB6FF15Q

Manufacturer:Banner

Alt. Part#:72108

Product Lifecycle:Active

Get a quick Quote!

WORLD-BEAM Q12 Series: Fixed-Field; Range: 15 mm; Input: 10-30 V dc; Output: DO (Dark Operate) Bipolar: 1 NPN; 1 PNP; 150 mm (6 in) M8 Pigtail QD

About the manufacturer: Banner is one of the manufacturers that offers Proximity Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the Q12RB6FF15Q Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    18.14368 g
  • Country Of Origin
    MX
  • IO Link
    No
  • DeviceNet
    No
  • Feature: Chemical Resistant
    No
  • Feature: Audible
    No
  • Feature: Timing (Hold/Delay)
    No
  • Feature: Hazardous Area
    No
  • Opposed Mode Emitter/Receiver
    N/A
  • Indicator
    LEDs
  • Feature: Encapsulated
    No
  • Max Op. Relative Humidity [%]
    95% @ 50°C
  • Barrel Diameter (mm)
    N/A
  • Adjustments
    N/A
  • Number of Pins
    4
  • IP Rating
    IP67
  • Lens Material
    Polycarbonate
  • Delay at Power-up (ms)
    120
  • Special Feature: Intrinsically Safe
    No
  • Special Feature: Remote Teach
    No
  • Special Feature: Water Detection
    No
  • Sensing Beam Wavelength
    640
  • Max Op. Temp. (°C)
    55
  • Repeatability (µs)
    175
  • Output response time (ms)
    0.85 ON/OFF
  • Min Op. Temp. (°C)
    -20
  • Operation
    Dark Operate
  • Connection
    Pigtail QD
  • Quick Disconnect Type
    M8 (Pico)
  • Outputs
    Bipolar (NPN & PNP)
  • Max Sensing Distance (mm)
    15
  • Power Supply/Supply Voltage
    10-30 V dc
  • Input/Output
    Discrete
  • Small Visible Spot
    LED
  • Housing Style
    Rectangular
  • Primary Housing Material
    Thermoplastic
  • Sensing Mode (Detailed)
    Background Suppression (Fixed)
  • Sensing Mode (General)
    Proximity
  • Power
    DC
  • Sensing Beam
    Visible Red LED
  • Cable Length (m)
    0.15
  • Light Color
    Visible red
  • Response time
    0.7ms / 0.0007 s
  • Ambient air temperature for operation
    -20...+55 °C
  • Product series / family name
    WORLD-BEAM series
  • Design
    background suppression system
  • Degree of protection
    IP67
  • Compliant with standard(s)
    cURus CE
  • Wavelength
    640 nm
  • Sensing distance
    15mm
  • Shape
    Rectangular
  • Operating mode
    Dark-ON
  • Primary brand
    Banner Engineering
  • Sub-range name
    Q12 series
  • Connection type
    Pre-wired with 6" / 150mm pigtail terminated with 4-pin Pico-style M8 connector
  • Material
    thermoplastic housing Polycarbonate lns.
  • Order code / Manufacturer SKU
    72108
  • Main function
    Sensor (Photo-electric)
  • Functions
    Fixed-field photo-electric sensor green LED (power ON) yellow LED (signal)
  • Supply voltage (DC)
    10Vdc-30Vdc (12Vdc / 24Vdc nom.)
  • Digital outputs
    1 x digital output (PNP/NPN transistor)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Q12RB6FF15Q Description

Banner Engineering Q12RB6FF15Q is a fixed-field photo-electric sensor designed with a background suppression system. It operates within an ambient air temperature range of -20 to +55°C and is housed in a thermoplastic with a polycarbonate lens. This sensor is pre-wired with a 6-inch (150mm) pigtail that terminates with a 4-pin Pico-style M8 connector. Part of the Q12 series, it offers an IP67 degree of protection, making it suitable for various industrial environments. The supply voltage requirement is between 10Vdc and 30Vdc, with nominal values at 12Vdc and 24Vdc. Its rectangular shape is engineered for precise installation, and it features a sensing distance of 15mm. The sensor emits visible red light with a wavelength of 640 nm and operates in a Dark-ON mode. It includes 1 x digital output (PNP/NPN transistor) and boasts a rapid response time of 0.7ms (0.0007 seconds).

Related documents Q12RB6FF15Q Specs

Q12RB6FF15Q 119223.pdf
