PIAT46TMB5 Banner Through Beam Sensors

Name: PIAT46TMB5
Brand: Banner
Price: 341 USD
Availability: BackOrder

Part#:PIAT46TMB5

Alt. Part#:70865

Manufacturer:Banner

Category:Through Beam Sensors

Product Lifecycle:Active

Product description

Plastic Fiber, Opposed Mode; Core Dia.: 1 mm; Fiber Length 2 m; Angle, Thread; SteelSkin, TMB5 Termination

Product Details

Weight
90.7184 g
Country Of Origin
JP
Measured Max Distance (mm)
440
Fiber Sensing End Size - Mounting Area
M4
Max Distance: DF-G1 (mm)
440
Max Distance: DF-G2 (mm)
714
Max Distance: DF-G3 (mm)
3422
Application: Vacuum Feed Through
None
Tariff Fiber Meters (fbm)
4
Application: Liquid Level
No
Termination Type
Plastic Fiber Sensors
Feature: Small Object Detection
No
Feature: Extended Range
No
Feature: Chemical Resistant
No
Integrated Lens
No
Minimum Repeat Bending Endurance
1000
Max Temp ( °C)
70
Termination
Terminated
Minimum Bend Radius (mm)
12
Retractile
No

Core Diameter (mm)

Flex Relief

Sensing End Segment 3

Thread

Sensing End Segment 2

Thread

Sensing End Segment 1

Angle

Fiber Sensing End Tip

Thread

Fiber Sensing End Size

M2.5

Fiber Length (m)

Sensing End Material (Specific)

Stainless Steel

Sensing Mode (General)

Opposed

Fiber Sheathing Material (Jacket)

STEELSKIN

Beam Exit

Right Angle

Sensing Mode (Detailed)

Reflective

Fiber Optic Type

Plastic

Housing Style

Round

Quantity Included

Max Range: DF-G3 (mm)

>3m - <=5m

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PIAT46TMB5 on Powermatic Associates is $341.00. Order now.

About the product

Banner Engineering PIAT46TMB5 is a fiber optic sensor designed for through-beam system applications, functioning as an opposed mode pair of individual fibers positioned side by side with right-angled sensing. This sensor is part of the Plastic fiber series and features a 1mm fiber core diameter. It is equipped with a cylindrical (threaded) end tip made of stainless steel, while the fiber itself is encased in a Steelskin fiber sheath for enhanced durability. The total length of the fiber is 6ft (approximately 2m), and it is engineered to operate efficiently in ambient air temperatures up to +70°C.

PIAT46TMB5 Related Documents

PIAT 4 SERIES TERMINATED-1630954999176.stp PIAT 4 SERIES TERMINATED-1630954999163.pdf
