PIAT415U Banner Through Beam Sensors

Name: PIAT415U
Brand: Banner
Price: 101 USD
Availability: BackOrder

Part#:PIAT415U

Alt. Part#:56081

Manufacturer:Banner

Category:Through Beam Sensors

Product Lifecycle:Active

Product description

Plastic Fiber, Opposed Mode; Core Dia.: 1 mm; Fiber Length 5 m; Angle, Thread; Free cut

Product Details

Weight
72.57472 g
Country Of Origin
JP
Fiber Sensing End Size - Mounting Area
M4
Max Distance: DF-G2 (mm)
No Data
Max Distance: DF-G1 (mm)
No Data
Max Distance: DF-G3 (mm)
No Data
Measured Max Distance (mm)
No Data
Application: Liquid Level
No
Feature: Small Object Detection
No
Tariff Fiber Meters (fbm)
10
Integrated Lens
No
Minimum Repeat Bending Endurance
10000
Feature: Extended Range
No
Flex Relief
No
Core Diameter (mm)
1
Sensing End Segment 1
Angle
Sensing End Segment 2
Thread
Sensing End Segment 3
Thread
Beam Exit
Right Angle
Quantity Included
2

Fiber Sensing End Tip

Thread

Fiber Optic Type

Plastic

Fiber Sheathing Material (Jacket)

Polyethylene

Application: Vacuum Feed Through

None

Termination Type

Plastic Fiber Sensors

Feature: Chemical Resistant

Max Temp ( °C)

Termination

Free Cut

Minimum Bend Radius (mm)

Retractile

Fiber Length (m)

4.572

Fiber Sensing End Size

M2.5

Sensing Mode (Detailed)

Reflective

Sensing End Material (Specific)

Stainless Steel

Sensing Mode (General)

Opposed

Housing Style

Round

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PIAT415U on Powermatic Associates is $101.00. Order now.

About the product

Banner Engineering PIAT415U is a fiber optic sensor designed for use in applications requiring precise detection through a through-beam system or opposed mode pair of individual fibers positioned side by side with right-angled sensing. It features a 1mm fiber core diameter and falls under the Plastic fiber series. The sensor has a cylindrical (threaded) end tip, with the sensing end made of stainless steel and the fiber sheathed in polyethylene (PE), ensuring durability and compatibility with various environments. It is capable of operating in ambient air temperatures up to +70°C and has a length of 20ft (6m), providing flexibility for installation in different settings.

PIAT415U Related Documents

PIAT4 SERIES UNTERMINATED-1630954971114.pdf PIAT4 SERIES UNTERMINATED-1630954971118.stp

$101.00

Your price can be lower.
Log in or Create account to check your discount

Stock:

Select Qty:

$101.00

$101.00 each

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

Compare PIAT415U with other Through Beam Sensors products

Weight

Country Of Origin

Fiber Sensing End Size - ...

Max Distance: DF-G2 (mm)

Max Distance: DF-G1 (mm)

Max Distance: DF-G3 (mm)

Measured Max Distance (mm...

Application: Liquid Level

Feature: Small Object Det...

Tariff Fiber Meters (fbm)

Selected product

Backordered

PIAT415U

Banner

Plastic Fiber, Opposed Mode; Core Dia.: 1 mm; Fiber Length 5 m; Angle, Thread; Free cut

Weight72.57472 g

Country Of OriginJP

Fiber Sensing End Size - Mounting AreaM4

Max Distance: DF-G2 (mm)No Data

Max Distance: DF-G1 (mm)No Data

Max Distance: DF-G3 (mm)No Data

Measured Max Distance (mm)No Data

Application: Liquid LevelNo

Feature: Small Object DetectionNo

Tariff Fiber Meters (fbm)10

10 in stock

PIA46UMJ1.3

Banner

Plastic Fiber, Opposed Mode; Core Dia.: 1 mm; Fiber Length 2 m; Angle; Free cut

Weight27.21552 g

Country Of OriginJP

Fiber Sensing End Size - Mounting Area-

Max Distance: DF-G2 (mm)-

Max Distance: DF-G1 (mm)-

Max Distance: DF-G3 (mm)-

Measured Max Distance (mm)-

Application: Liquid Level-

Feature: Small Object Detection-

Tariff Fiber Meters (fbm)-

58 in stock

PBT26UMSSMFF

Banner

Plastic Fiber, Diffuse Reflective; Core Dia.: 0.5 mm; Fiber Length 2 m; Thread; Free cut

Weight25.401152 g

Country Of OriginTW

Fiber Sensing End Size - Mounting Area-

Max Distance: DF-G2 (mm)-

Max Distance: DF-G1 (mm)-

Max Distance: DF-G3 (mm)-

Measured Max Distance (mm)-

Application: Liquid Level-

Feature: Small Object Detection-

Tariff Fiber Meters (fbm)-

About the manufacturer

Powermatic Associates is an authorized Banner distributor, proud to offer an extensive range of Banner's innovative products and solutions. Banner Engineering is a renowned manufacturer specializing in industrial automation, known for their cutting-edge sensor technology, machine safety solutions, wireless connectivity, and LED lighting systems. With a precision focus on delivering high-quality eq...
