M18TIP14 Banner Temperature Sensors

Product Details

• Weight
  204.1164 g
• Country Of Origin
  US
• Common Ethernet Protocol
  No
• Wireless
  No
• 1-wire Serial Interface
  Yes
• SSI
  No
• IO Link
  No
• RS-232
  No
• Profibus
  No
• PROFINET
  No
• RS-422
  No
• Feature: Health/ Marginal Signal Output
  Yes
• RS-485
  No
• Feature: Quick Disconnect
  Yes
• Feature: Chemical Resistant
  Yes
• Feature: Pump-in/ Pump-out
  No
• Feature: Timing (Hold/Delay)
  No
• Feature: Remote Teach
  Yes
• Remote Teach and Laser Control Input Impedence
  3 kΩ
• Minimum Window Size (mm)
  3 °C
Barrel Diameter (mm)
18
Analog Linearity (mm)
From 0 °C to +50 °C: ± 2 °C From +50 °C to +300 °C: ±1 °C or ±1%, whichever is greater
Minimum Response Time (ms)
25
Warm-up Time (minutes)
5
Min Operating Temperature (°C)
-20
Window Material
Germanium
NEMA Rating
NEMA 6
IP Rating
IP67
Max Operating Temperature (°C)
70
Storage Temperature (°C)
-25 to 75
Analog Current Output Rating
1 kΩ max @24 V dc, max load resistance = [(Vcc-4 V)/0.02 A] Ω
Number of Pins
5
Adjustments
Push Button; Remote Teach
Delay at Power-up (ms)
1500
Quick Disconnect Type
No QD
Power Supply
12-30 V dc
Analog Resolution/Discrete Repeatability
± 1% of measurement, or ± 1 °C, whichever is greater
Analog Output Configuration
4-20 mA
Connection
Flying Leads
Indicator
LED(s)
Input/Output
Analog
PC Configurable
Yes
Sensing Mode (Detailed)
Diffuse
Sensing Mode (General)
Proximity
Sensing Beam
N/A
Cable Length (m)
2
Device Type
Sensor
Power
DC
Housing Style
Barrel
Primary Housing Material
Stainless Steel
