M18TB8Q Banner Temperature Sensors

M18TB8Q on Powermatic Associates
Banner

Part#:M18TB8Q

Manufacturer:Banner

Category:Temperature Sensors

Alt. Part#:73646

Product Lifecycle:Active

Get a quick Quote!

M18T Series: Temperature Sensor; 8: 1 Integrated Lens; Output: one NPN, one PNP; 5-pin M12 Integral QD

About the manufacturer: Banner is one of the manufacturers that offers Temperature Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the M18TB8Q Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    99.79024 g
  • Country Of Origin
    US
  • Profibus
    No
  • 1-wire Serial Interface
    Yes
  • Wireless
    No
  • SSI
    No
  • IO Link
    No
  • Common Ethernet Protocol
    No
  • RS-485
    No
  • PROFINET
    No
  • RS-422
    No
  • RS-232
    No
  • Feature: Quick Disconnect
    Yes
  • Feature: Chemical Resistant
    Yes
  • Feature: Pump-in/ Pump-out
    No
  • Feature: Timing (Hold/Delay)
    No
  • Remote Teach and Laser Control Input Impedence
    3 kΩ
  • Minimum Window Size (mm)
    3 °C
  • Feature: Remote Teach
    Yes
  • Barrel Diameter (mm)
    18
  • Minimum Response Time (ms)
    25
  • Warm-up Time (minutes)
    5
  • Min Operating Temperature (°C)
    -20
  • Max Operating Temperature (°C)
    70
  • IP Rating
    IP67
  • Storage Temperature (°C)
    -25 to 75
  • Number of Pins
    5
  • NEMA Rating
    NEMA 6
  • Delay at Power-up (ms)
    1500
  • Analog Resolution/Discrete Repeatability
    1 °C
  • Connection
    Integral QD
  • Sensing Mode (Detailed)
    Diffuse
  • Power Supply
    12-30 V dc
  • PC Configurable
    Yes
  • Indicator
    LED(s)
  • Quick Disconnect Type
    M12 (Euro)
  • Primary Housing Material
    Stainless Steel
  • Sensing Mode (General)
    Proximity
  • Device Type
    Sensor
  • Housing Style
    Barrel
  • Input/Output
    Discrete
  • Adjustments
    Push Button; Remote Teach
  • Power
    DC
  • Sensing Beam
    N/A
  • Primary brand
    Banner Engineering
  • Design
    integrated optical lns.
  • Thread size
    M18
  • Response time
    25ms / 0.025 s
  • Sub-range name
    M18T series
  • Supply voltage (DC)
    12Vdc-30Vdc (24Vdc nom.)
  • Shape
    Cylindrical threaded/barrel
  • Degree of protection
    IP67 NEMA 6
  • Product series / family name
    T-GAGE series
  • Temperature
    0...+300°C measurement range
  • Digital outputs
    1 x digital output (PNP transistor) 1 x digital output (NPN transistor)
  • Ambient air temperature for operation
    -20...+70 °C
  • Main function
    Sensor (Temperature)
  • Functions
    Non-contact Infrared (IR) temperature switch/sensor green LED (power ON) amber LED (output state) red LED (teach active) TEACH mode
  • Connection type
    Pre-equipped with 5-pin Euro-style M12 connector
  • Material
    stainless steel (304) housing ABS / polycarbonate p.button housing santoprene (p. button) Integrated lens Acrylic lightpipes
  • Compliant with standard(s)
    cURus CE
  • Order code / Manufacturer SKU
    73646

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

M18TB8Q Description

Banner Engineering M18TB8Q is a non-contact Infrared (IR) temperature switch/sensor belonging to the M18T series. This sensor features an integrated optical lens and TEACH mode for precise operation. It has an M18 cylindrical threaded/barrel shape with a housing made of Stainless steel 304, an ABS / Polycarbonate (PC) push button housing, Thermoplastic vulcanizate (TPV) push button, an integrated lens, and Acrylic light pipes. It comes pre-equipped with a 5-pin Euro-style M12 connector for connectivity. The M18TB8Q operates on a supply voltage of 12Vdc-30Vdc (24Vdc nominal) and can measure temperatures ranging from 0 to +300°C. It is designed to operate in ambient air temperatures from -20 to +70 °C. This sensor offers a high degree of protection with an IP67 NEMA 6 rating, ensuring durability in various environments. It features an M18 thread size and provides 1 x digital output (PNP transistor) and 1 x digital output (NPN transistor) with a response time of 25ms / 0.025 s.

Related documents M18TB8Q Specs

M18TB8Q 120632.pdf
