M18TB6EQ Banner Temperature Sensors

Name: M18TB6EQ
Brand: Banner
Price: 397 USD
Availability: BackOrder

Part#:M18TB6EQ

Manufacturer:Banner

Alt. Part#:73649

Product Lifecycle:Active

Get a quick Quote!

M18T Series: Temperature Sensor; 6: 1 Plastic Fresnel Lens; Output: one NPN, one PNP; 5-pin M12 Integral QD

About the manufacturer: Banner is one of the manufacturers that offers Temperature Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the M18TB6EQ Banner price in the box on the right side or send a quick quote.

Product Details

Weight
99.79024 g
Country Of Origin
US
1-wire Serial Interface
Yes
SSI
No
Profibus
No
RS-485
No
Wireless
No
RS-422
No
IO Link
No
Feature: Pump-in/ Pump-out
No
Feature: Timing (Hold/Delay)
No
PROFINET
No
Common Ethernet Protocol
No
RS-232
No
Feature: Quick Disconnect
Yes
Feature: Chemical Resistant
Yes
Feature: Remote Teach
Yes
Remote Teach and Laser Control Input Impedence
3 kΩ
Minimum Window Size (mm)
3 °C
Max Operating Temperature (°C)
70

Warm-up Time (minutes)

Minimum Response Time (ms)

Min Operating Temperature (°C)

-20

Barrel Diameter (mm)

Storage Temperature (°C)

-25 to 75

NEMA Rating

NEMA 6

IP Rating

IP67

Number of Pins

Adjustments

Push Button; Remote Teach

Delay at Power-up (ms)

1500

Power Supply

12-30 V dc

Analog Resolution/Discrete Repeatability

1 °C

Quick Disconnect Type

M12 (Euro)

Connection

Integral QD

Indicator

LED(s)

Input/Output

Discrete

Device Type

Sensor

Primary Housing Material

Stainless Steel

Power

Sensing Beam

N/A

PC Configurable

Yes

Sensing Mode (General)

Proximity

Housing Style

Barrel

Sensing Mode (Detailed)

Diffuse

Main function

Sensor (Temperature)

Sub-range name

M18T series

Thread size

M18

Response time

25ms / 0.025 s

Primary brand

Banner Engineering

Design

enclosed plastic optical lns.

Digital outputs

1 x digital output (PNP transistor) 1 x digital output (NPN transistor)

Ambient air temperature for operation

-20...+70 °C

Supply voltage (DC)

12Vdc-30Vdc (24Vdc nom.)

Temperature

0...+300°C measurement range

Order code / Manufacturer SKU

73649

Product series / family name

T-GAGE series

Connection type

Pre-equipped with 5-pin Euro-style M12 connector

Material

stainless steel (304) housing ABS / polycarbonate p.button housing santoprene (p. button) Enclosed plastic lens Acrylic lightpipes

Functions

Non-contact Infrared (IR) temperature switch/sensor green LED (power ON) amber LED (output state) red LED (teach active) TEACH mode

Shape

Cylindrical threaded/barrel

Degree of protection

IP67 NEMA 6

Compliant with standard(s)

cURus CE

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

M18TB6EQ Description

Banner Engineering M18TB6EQ is a non-contact infrared (IR) temperature switch/sensor belonging to the M18T series. This sensor features an enclosed plastic optical lens and operates in TEACH mode. It has an M18 cylindrical threaded/barrel shape with a housing made of stainless steel 304. The push button housing is constructed from ABS / Polycarbonate (PC), with a thermoplastic vulcanizate (TPV) push button and acrylic light pipes. It comes pre-equipped with a 5-pin Euro-style M12 connector for connectivity. The M18TB6EQ operates on a supply voltage of 12Vdc-30Vdc, with a nominal 24Vdc, and can measure temperatures ranging from 0 to +300°C. It is designed to function in ambient air temperatures from -20 to +70°C. This sensor offers a degree of protection rated at IP67 NEMA 6, ensuring its durability in various environments. It features an M18 thread size and provides digital outputs through 1 x PNP transistor and 1 x NPN transistor, with a response time of 25ms / 0.025 s.
