K50LTXXPPB2Q Banner Electronic Components

Product Details

• Modbus RTU
  No
• Pro-Editor Compatible (Discrete)
  No
• Wireless
  No
• IO Link
  No
• Multi-Color Device
  Single Color On
• Feature: Quick Disconnect
  Yes
• Feature: Chemical Resistant
  No
• Feature: Audible
  No
• Feature: Hazardous Area
  No
• Secondary Material
  Thermoplastic
• Primary Window Material
  Polycarbonate Diffused
• Button Operation
  Momentary
• Primary Housing Color
  Black
• Storage Temp (°C)
  -40 to 70
• Operation
  Normally Open
• Min Op. Temperature (°C)
  -40
• Max Op. Temperature (°C)
  50
• Max Op. Relative Humidity Non-Condensing (%)
  90% @ 50°C
• NEMA Type and UL Type Rating
  NEMA and UL 4X, 13
• Environmental Rating
  IP65
Physical Dimensions (LxWxH or DxH mm)
50.0 x 74.7
Input Type
PNP
Output Type
Dry Contact
Supply Voltage
12-30 V dc
Animation Option 1
Solid On
Color Option 1
Turquoise
Number of Colors / Segments
1
Color Technology
Standard LED
Product Size (mm)
50
Number of Input Pins/Conductors
4
Max Current Color (mA)
65
Quick Disconnect Type
M12 (Euro)
Connection
Integral QD
Power Source
DC
Actuation
Yes
Color Input Control
Individual (One wire/color, same number of colors as input wires)
Housing Style
Base Mount - Dome Window
Mounting Thread
M30 x 1.5
Activation Function
Push-Button
Primary Housing Material
Polycarbonate
Power
DC
