Compact power supply module in IP67, 24 VDC output voltage - 3.8 A output current, , Broad temperature range, Status LED, AC and DC wide-range input, Mains buffering up to 50 ms, High efficiency, No-load and short-circuit proof, Natural air cooling

Compact power supply module in IP67, 24 VDC output voltage - 2 x 3.8 A output current, , Broad temperature range, Status LED, AC and DC wide-range input, Mains buffering up to 50 ms, High efficiency, No-load and short-circuit proof, Natural air cooling, Current limited to meet UL1310, NEC class 2

Power Supply, 480W, AC 100-240V input, 1 phase, 48-56Vdc output, 10A, DC-OK relay contact

PULS PIM36.241 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion capabilities. It operates within an ambient air temperature range of -10 to +60°C with linear derating up to +70°C. The unit is equipped with a NEC Class 2 DC-OK relay contact output and provides a rated current of 5A at 12Vdc within the -10 to +60°C range and 3.8A at 12Vdc at +70°C. Connection is facilitated through push-in spring connections. The supply voltage (AC) spans from 90Vac to 264Vac for nominal inputs like 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at a frequency of 47-63Hz, with an input overvoltage tolerance of 264-300Vac for up to 500ms, a turn-ON voltage of 75Vac, and a shutdown voltage of 54Vac. This part of the PIM-series measures W36mm x H90mm x D91mm, has an IP20 degree of protection, and is housed in polycarbonate (PC). It supports a single-phase (1AC) network, has a net width of 36mm, and offers a rated power of 60W at -10 to +60°C, which derates linearly to 45.6W at +70°C. The output voltage (DC) is adjustable between 12Vdc and 15Vdc, with protection functions including output overvoltage protection and overload/short-circuit protection. Efficiency rates are 0.907 at 230Vac input and 0.902 at 120Vac input. Current consumption is 0.6A at 230Vac input (full output), 1A at 120Vac input (full output), and 1.15A at 100Vac input (full output), with a peak inrush of 44A at 230Vac input and 18A at 120Vac input. The unit has a start-up delay of 50-60ms, a rise time of 18ms max at nominal input with full constant current load and 0mF load capacitance, and a hold time of 107ms at 230Vac input. Power dissipation/losses are 6.2W at 230Vac input and 6.5W at 120Vac input under full output load. Electrical durability is noted at various conditions, with the highest being 724000 hours at 25°C, 2.5A, 1AC 230Vac input. Ripple is specified at 100mVpp (20Hz...20MHz; 50Ω), and the output stage capacitance is 2200µF.

PULS PIM60.125 is a power supply unit that functions as an AC/DC PSU/converter with DIN rail mounting. It operates within an ambient air temperature range of -10 to +60°C with linear derating up to +70°C. This unit features a NEC Class 2 DC-OK relay contact output and provides a rated current of 2.5A at 24Vdc within -10 to +60°C and 1.9A at 24Vdc at +70°C. It offers push-in spring connections for ease of installation. The supply voltage (AC) ranges from 90Vac to 264Vac across various nominal voltages and frequencies, with specific input overvoltage and shutdown voltage parameters. The PIM-series unit measures W36mm x H90mm x D91mm, has an IP20 degree of protection, and is housed in a polycarbonate (PC) material. Designed for single-phase (1AC) networks, it has a net width of 36 mm and delivers a rated power of 60W at -10 to +60°C, which derates linearly to 45.6W at +70°C. The output voltage (DC) is adjustable between 24Vdc and 28Vdc, with specific protection functions against overvoltage and overload/short-circuit conditions. It does not support series or parallel operation and is resistant to back-feeding loads. The efficiency rates are 0.918 and 0.907 for 230Vac and 120Vac inputs, respectively. Current consumption varies with input voltage, and the unit exhibits specific start-up delay, rise time, and hold time characteristics. Power dissipation/losses are detailed for different input conditions, and the electrical durability is specified across various operational conditions. The ripple is noted at 100mVpp, and the output stage capacitance is 900 µF.

Power supply with integrated decoupling function, 240W, AC 100-240V | DC 110-300V input, 1 phase, 24Vdc output, 10A, hot swappable, enhanced DC input

PULS CP5.241-M1 is a power supply unit designed for DIN rail mounting with an aluminium housing. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 32mm. The unit features a current consumption of 7A peak max. inrush at both 230Vac and 120Vac input. Its efficiency rates are 0.943 at 230Vac input, 0.936 at 120Vac input, and 0.929 at 100Vac input. The dimensions of the CP5.241-M1 are W32mm x H124mm x D102mm. It has a start-up delay time of 380-420ms for 100-230Vac input, with rise times of 80ms under nominal input with a constant full current load and 0mF load capacitance, and 100-110ms with 5mF load capacitance. The unit includes protection functions such as output overvoltage protection and overload/short-circuit current protection, with a resistance to back-feeding loads up to 35V. Power dissipation/losses are 7.3W at 230Vac input and 8.2W at 120Vac input, with an output stage capacitance of 1800µF. Electrical durability varies with conditions, reaching up to 775,000 hours at 25°C and 2.5A output with 1AC 230Vac input. The ripple is 50mVpp across 20Hz to 20MHz at 50Ω. This AC/DC power supply unit, part of the CP-series designed for medical applications, features a DC-OK relay contact output and spring-clamp connections. It supports a supply voltage range of 85Vac-264Vac, with an overvoltage input range of 264-300Vac for up to 500ms, and has a rated current of 5A at 24Vdc with a derating above 60°C. The unit provides a single-phase supply, with a rated power of 120W and an adjustable output voltage of 24Vdc-28Vdc. The hold time is 35ms at both 120/230Vac input.

PULS CP10.122 is a DIN rail mounting power supply unit enclosed in an aluminium housing, designed for an ambient air temperature range of -25 to +70°C. It features a net width of 39mm and dimensions of W39mm x H124mm x D117mm. The unit has a current consumption of 11A peak max. inrush at 230Vac input and 7A peak max. inrush at 120Vac input. Its efficiency rates are 0.943 at 230Vac input, 0.928 at 120Vac input, and 0.921 at 100Vac input. The CP10.122 offers a start-up delay of 240-300ms for 100-230Vac input, with rise times of 18ms and 35ms under specified conditions. It includes protection functions such as output overvoltage protection and overload/short-circuit current protection, with capabilities for series/parallel operation and resistance to back-feeding loads up to 25V. Power dissipation/losses are 11.6W at 230Vac input and 14.9W at 120Vac input, with an output stage capacitance of 5350µF. The electrical durability varies with conditions, reaching up to 534000 hours. The ripple is specified at 50mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit, part of the CP-series, features a 20% power reserve, shutdown input, extended DC input, and DC-OK relay contact output, with screw-clamp connections. It supports a supply voltage range of 88Vdc-180Vdc and 85Vac-264Vac, with a rated current of 16A at 12Vdc, and offers a rated power of 192W. The output voltage is adjustable between 12Vdc and 15Vdc, with a 200mV turn-ON overshoot and a hold time of 50ms. It is suitable for single-phase (1AC) or DC networks.

PULS CP20.241-C1 is a DIN rail mounting power supply unit housed in aluminium, designed for operation in ambient air temperatures ranging from -25 to +70°C. It features a net width of 48mm and dimensions of W48mm x H124mm x D127mm. The unit has a current consumption of 11A peak max. inrush at 230Vac input and 7A peak max. inrush at 120Vac input, with efficiencies of 0.956, 0.942, and 0.936 at 230Vac, 120Vac, and 100Vac inputs respectively. It is chemically resistant with a conformal coated PCB suitable for harsh environments. The CP20.241-C1 offers a 450ms start-up delay and rise times of 145ms and 160ms under specified conditions. It includes protection functions such as output overvoltage protection and overload/short-circuit protection, with capabilities for series/parallel operation and handling back-feeding loads up to 35V. Power dissipation/losses are 22.1W and 29.6W for 230Vac and 120Vac inputs at full output load, respectively. The output stage capacitance is 8500µF, and the unit demonstrates electrical durability across various conditions, with ripple at 50mVpp. It functions as an AC/DC power supply unit with a 20% power reserve, part of the CP-series, featuring ATEX approval, conformal coating, and a DC-OK relay contact output. Connection is via screw-clamp connections, with supply voltages of 88Vdc-180Vdc and 85Vac-264Vac, rated current of 20A at 24Vdc, and a rated power of 480W. The output voltage is adjustable between 24Vdc and 28Vdc, with a 32ms hold time at 120/230Vac input.

Compact power supply module in IP67, 24 VDC output voltage - 3.8 A output current, , Broad temperature range, Status LED, AC and DC wide-range input, Mains buffering up to 50 ms, High efficiency, No-load and short-circuit proof, Natural air cooling, Current limited to meet UL1310, NEC class 2
