PULS XT40.242 is a power supply unit part of the X-series, designed to function as an AC/DC PSU/converter with a semi-regulated 25% power reserve and a DC-OK relay contact output. It operates on a supply voltage of 3x432-528Vac (with nominal values of 440Vac, 480Vac, 500Vac, 525Vac; frequency 47-63Hz), a turn-on voltage of 3 x 390Vac, and a shutdown voltage of 3 x 355Vac. The unit is housed in aluminium, measures W96mm x H124mm x D159mm, and features screw-clamp connections for installation. It is rated for a current of 40A at 24Vdc and is designed for DIN rail mounting in a 3-phase (3AC) network. The ambient air temperature for operation ranges from -25 to +70°C. The XT40.242 has a peak inrush current consumption of 4A (at 3x480Vac input), a rated power of 960W at 24Vdc (1200W for typ. 15s), and includes protection functions such as output overvoltage protection (29.9Vdc max.) and overload/short-circuit current protection. It is not suitable for parallel operation to increase output power but supports 1+1 redundancy for higher system availability. The unit's efficiency is rated at 0.955 (at 3x480Vac input), with a 350ms start-up delay, and output voltage fixed at 24Vdc. The hold time is 2ms (at 3x480Vdc input), and power dissipation/losses are 45.2W (at full output load). Its electrical durability is rated at 51000 hours (at 40°C; 40A output; 3AC 480Vdc input) and 142000 hours (at 25°C; 40A output; 3AC 480Vdc input), with an output stage capacitance of 20000µF and a ripple of 1500mVpp.

PULS ML50.105 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and is classified under NEC Class 2 design. The unit provides a rated current of 1.05A at 48Vdc with a power derating from 1.3W at +60°C to +70°C. It features spring-clamp connections for secure and reliable connectivity. The supply voltage ranges from 85Vac to 264Vac for AC input (with specific nominal values including 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at a frequency of 47-63Hz, a turn-ON voltage of 65Vac, and a shutdown voltage of 55Vac) and from 88Vdc to 375Vdc for DC input (with nominal values such as 100Vdc, 110Vdc, 120Vdc, 127Vdc, 200Vdc, 220Vdc, and 250Vdc). The housing is made from a PC / ABS blend, ensuring durability within its specified environment. This unit is compatible with single-phase (1AC) or DC networks, has a net width of 45 mm, and offers a rated power of 50W. The output voltage is adjustable between 48Vdc and 56Vdc, with a 400mV turn-ON overshoot. It boasts an efficiency of 0.9 with a 230Vac input, a maximum inrush current consumption of 17A at 120Vac input and 35A peak at 230Vac input, and includes a 32s start-up delay for 100-230Vac input with a 48ms rise time under nominal input conditions. Power dissipation/losses are rated at 6W, with a ripple of 200mVpp across a frequency range of 20Hz to 20MHz at 50Ω, and an output stage capacitance of 1600 µF.

PULS ML50.109 is a power supply unit designed for AC/DC conversion and is suitable for DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and features a NEC Class 2 conformal coating with a DC-OK relay contact output. The unit provides a rated current of 2.1A at 24Vdc and utilizes spring-clamp connections for connectivity. It supports a wide supply voltage range from 85Vac to 264Vac for AC (with specific nominal values and a 65Vac turn-ON voltage and 55Vac shutdown voltage) and from 82Vdc to 380Vdc for DC, accommodating various network configurations including single-phase (1AC) or DC. The ML50.109 measures 45mm in width, 75mm in height, and 91mm in depth, and is housed in a PC/ABS blend material. It delivers a rated power of 50W with an adjustable output voltage range of 24Vdc to 28Vdc. The unit is designed with protection functions including an NTC for input inrush current limiting and boasts an efficiency of up to 0.89 depending on the input voltage. It has a maximum current consumption of 17A at 120Vac input and 35A peak at 230Vac input, with a power dissipation/loss of 6.2W. The electrical durability of the ML50.109 is rated at a minimum of 54,000 hours at +40°C, and it features a ripple of 50mVpp across a frequency range of 20Hz to 20MHz. The output stage capacitance is 1600µF, ensuring stable operation across its service life.

PULS ML100.200 is a power supply unit designed for AC/DC conversion with DIN rail mounting capabilities. It operates within an ambient air temperature range of -10 to +70°C and offers a rated current of 4.2A at 24Vdc, with a derating of 2.5W from +60°C to +70°C. The unit features spring-clamp connections for secure installation and supports a wide supply voltage range of 323Vac to 576Vac, accommodating various nominal voltages such as 380Vac, 400Vac, 415Vac, 440Vac, 480Vac, 500Vac, and 525Vac across a frequency range of 47-63Hz, suitable for 2-phase input networks. With dimensions of W72.5mm x H75mm x D103mm and constructed from a PC/ABS blend housing, the ML100.200 has a net width of 72.5 mm. It delivers a rated power of 100W and an adjustable output voltage range of 24Vdc to 28Vdc. The unit is equipped with an NTC for input inrush current limitation, achieving efficiencies of 0.895 and 0.89 at 400Vac and 480Vac inputs, respectively. It has a maximum inrush current consumption of 36A at 2x400Vac input and 45A peak at 2x480Vac input, with power dissipation/losses of 11.7W and a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω.

Power Supply, 240W, AC 200-240V input, 1 phase, 24-28Vdc output, 10A, DC-OK relay contact

PULS CP5.241-C1 is a DIN rail mounting power supply unit with an aluminium housing, designed for an ambient air temperature range of -25 to +70°C. It features a net width of 32mm and dimensions of W32mm x H124mm x D102mm. This unit has a current consumption of 7A peak max. inrush at both 230Vac and 120Vac input, with efficiencies of 0.943, 0.935, and 0.927 at 230Vac, 120Vac, and 100Vac inputs respectively. The CP5.241-C1 is equipped with a conformal coated PCB for resistance to harsh environments. It offers a start-up delay of 380-420ms and rise times of 80ms and 100ms under specified conditions. Protection functions include output overvoltage protection and overload/short-circuit protection, with capabilities for series/parallel operation and 1+1 redundancy using a redundancy module. Power dissipation/losses are 7.3W and 8.2W at full output load for 230Vac and 120Vac inputs, respectively. The output stage capacitance is 1800µF, and electrical durability ranges from 96,000 to 775,000 hours under various conditions. The ripple is 50mVpp, and the unit functions as an AC/DC power supply with a 20% power reserve. It belongs to the CP-series and features a design with conformal coating, 20% power reserve, and DC-OK relay contact output. Connection is made via screw-clamp connections. Supply voltage ranges from 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc, and a rated power of 120W. The output voltage is adjustable between 24Vdc and 28Vdc, with a 200mV turn-ON overshoot and a hold time of 35ms.

PULS FPT500.241-002-101 is a power supply unit from the FPT500 Basic 3AC series designed for field AC/DC power supply or conversion. It features a DC-OK relay contact output within an aluminium housing and utilizes a HanQ4/2 female connector for input, a 5-pin M12 connector for DC-OK, and a HanQ4/0 connector for output. This unit offers protection against output overvoltage, overload, short-circuit, and over-temperature, with specific mechanisms for handling heavy overloads and automatic restarts under certain conditions. It does not support series or parallel operation and is designed to resist back-feeding loads up to 35V / 4J. The rated current is 20.8A at 24Vdc, with a supply voltage range of 323Vac-552Vac across various nominal voltages and frequencies. It is designed for hanging or screw mounting, operates within an ambient air temperature range of -25 to +70°C, and offers IP65 and IP67 protection. The unit operates on a 3-phase network, with specific current consumption and efficiency ratings based on input voltage. It provides a rated power of 600W to 350W depending on the operating temperature, with short-term power availability up to 1000W. The output voltage is adjustable between 24Vdc and 28Vdc, with a specified electrical durability and power dissipation/losses under different conditions.

Switching power supplies, , Output voltage adjustable 22.5…28.5 VDC, Nominal current 20 A, Single/parallel operating mode, Surge protection, Universal operating voltage, Mains failure bridging up to 30 ms, High efficiency, Parallel operation possible, Natural air cooling, Power-good relay, cULus listed, Safety extra-low voltage SELV IEC/EN 60950, SEMI-F47

Switching power supplies, , Output voltage adjustable 22.5…28.5 VDC, Nominal current 10 A, Single/parallel operating mode, Surge protection, Universal operating voltage, Mains failure bridging up to 30 ms, High efficiency, Natural air cooling, Power-good relay, cULus listed, Safety extra-low voltage SELV IEC/EN 60950, SEMI-F47

PULS QS5.DNET is a power supply unit designed for AC/DC conversion with DIN rail mounting. It operates within an ambient air temperature range of -25 to +70°C and is a NEC Class 2 DeviceNet approved unit featuring a DC-OK relay contact output. The unit provides a rated current of 3.8A at 24Vdc and utilizes spring-clamp connections for connectivity. It supports a wide supply voltage range from 85Vac to 264Vac across various nominal values and from 88Vdc to 360Vdc, with specific turn-on and shutdown voltages detailed for both AC and DC inputs. The QS5.DNET, part of the Q-series, measures 40mm in width, 124mm in height, and 117mm in depth, housed in an aluminium casing. It is compatible with single-phase (1AC) or DC networks, offering a rated power of 91.2W and a fixed output voltage of 24Vdc. Protection features include output overvoltage protection and mechanisms for handling overload, short-circuit conditions, and back-feeding loads. The unit boasts high efficiency rates varying with input voltage, specific current consumption peaks, and detailed time delays for start-up and rise times, alongside hold times for buffer periods. Power dissipation losses are provided for different input conditions, and the electrical durability is specified under various operational conditions. The output stage capacitance is 3500µF, and the ripple is maintained at 50mVpp across a wide frequency range.
