880-687 WAGO Terminal Blocks

880-687 on Powermatic Associates
WAGO

Part#:880-687

Manufacturer:WAGO

Category:Terminal Blocks

Product Lifecycle:Active

Product description

880-687 WAGO - 3-conductor ground terminal block; 4 mm²; side and center marking; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP®; 4,00 mm²; green-yellow

Product Details

  • Weight
    12.13900319 g
  • Country Of Origin
    Germany
  • HTS Code
    85369010000
  • Country of Origin
    Germany
  • Operating Temperature
    105 degrees celsius
  • Conductor Size
    12 american wire gauge, 4 millimeters
  • Weight
    12.139 grams
  • Actuator
    Operating Tool
  • Package Type
    Box
  • Flammability Class
    V0
  • Mounting Type
    DIN-35 Rail
  • Height
    2.874 inches, 73 millimeters
  • Conductor Material
    Copper
  • Width
    0.197 inches, 5 millimeters
  • Color
    Green, Yellow
  • Strip Length
    0.35 inches, 9 millimeters
  • Insulation Material
    Polyamide

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 880-687 on Powermatic Associates is $8.89. Order now.

About the product

Wago 880-687 is a ground/earthing terminal block featuring CAGE-CLAMP spring connections designed for a single deck/level with side and center marking slots. It is rated for an impulse voltage (Uimp) of 5 mm and has a net width for 1 grounding / protective-earth (1PE) connection. This terminal block is suitable for mounting on DIN-35 rail (35 x 15 / 35 x 7.5) and exhibits a green-yellow color for easy identification. It has dimensions of H73mm x W5mm x D29mm and is compatible with 0.08mm2 to 4mm2 fine stranded or solid conductors, as well as #28AWG to #12AWG fine stranded or solid conductors. The terminal block is constructed from Polyamide (PA) 66 and supports 3-wires (1 clamp + 2 clamps) (1+2) for normally closed (NC) auxiliary contacts.
