Name: 753-110
Brand: WAGO
Price: 5.29 USD
Availability: InStock

This item can ship within 24h!

750-1405

Wago 750-1405 is an I/O unit functioning as a standard DC digital input slice module. It operates with a supply voltage of 5Vdc provided by the system and an adjustable supply voltage of 18-32.5Vdc to field sensing devices. This unit features push-in spring cage-clamp connections and is designed for use in environments with an ambient air temperature range for operation from -25°C to +55°C and for storage from -40°C to +85°C. It supports a control voltage of 24Vdc with high-side switching and offers 16 digital inputs. The 750-1405 has an IP20 degree of protection and is mounted on a DIN-35 rail. Its housing is made of polycarbonate (PC) and polyamide (PA) 6.6, ensuring durability. The unit's digital inputs voltage ranges from -3 to +5Vdc (OFF) and 15-30Vdc (ON), with a trip current rating of 25mA at 5Vdc system supply. It features a vibration resistance according to EN 60068-2-6 of 4g and a shock resistance according to EN 60068-2-27 of 15g. The module is designed to withstand 95% relative humidity (non-condensing) and has a response time of 3ms with a filter. Its dimensions are H100mm x W12mm x D69mm, making it compact for efficient use of space.

WAGOSTOCK: 19

This item can ship within 24h!

750-1504

Wago 750-1504 is an I/O unit functioning as a standard DC digital output slice module. It operates with a supply voltage of 5Vdc provided by the system and an adjustable 18-32.5Vdc supply to field sensing devices. This unit features push-in spring cage-clamp connections and is designed for use in environments with an ambient air temperature range for operation from -25°C to +55°C and for storage from -40°C to +85°C. It supports a control voltage (DC) and offers short-circuit protection for control voltage (AC), with a degree of protection rated at IP20. The rated insulation voltage (Ui) is 12 mm, and the unit is designed for mounting on a DIN-35 rail. It has dimensions of H100mm x W12mm x D69mm and is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing. The module features 16 digital outputs (24Vdc / 500mA) with high-side switching and includes 1-wire analog inputs. It has a power dissipation/losses with vibration resistance according to EN 60068-2-6 -- 4g and shock resistance according to EN 60068-2-27 --15g. The unit consumes 40mA (5Vdc from the system supply) and 29mA (from the field supply with no external load). It is designed to operate within a climatic resistance of 95% relative humidity (RH), non-condensing.

WAGOSTOCK: 16

This item can ship within 24h!

750-1415

Wago 750-1415 is an I/O unit functioning as a standard DC digital input slice module. It operates with a supply voltage of 5Vdc provided by the system and an adjustable 18-32.5Vdc for field sensing devices. This unit features push-in spring cage-clamp connections and is designed for use in environments with an ambient air temperature ranging from -40°C to +55°C for operation and -40°C to +85°C for storage. It supports a control voltage of 24Vdc and utilizes an IP20 communication protocol. The rated insulation voltage is 12mm, and it is designed for mounting on a DIN-35 rail. The unit's dimensions are H100mm x W12mm x D69mm, and it is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing. It has 8 digital inputs with a 24Vdc transistor output and supports type-3 high-side switching. The digital inputs voltage ranges from -3 to +5Vdc (OFF) and 11-30Vdc (ON), with a trip current rating of 6mA for system supply and 2mA for field supply. It features a 3ms filter for digital inputs, vibration resistance according to EN 60068-2-6 at 4g, and shock resistance according to EN 60068-2-27 at 15g. The unit is designed to withstand up to 95% relative humidity (RH), non-condensing.

WAGOSTOCK: 18

This item can ship within 24h!

750-1515

Wago 750-1515 is an I/O unit functioning as a standard DC digital output slice module. It operates with a supply voltage of 5Vdc provided by the system and an adjustable supply to field sensing devices ranging from 18-32.5Vdc. This unit features push-in spring cage-clamp connections and is designed for operation in ambient air temperatures ranging from -40°C to +55°C, with storage temperatures from -40°C to +85°C. It supports a control voltage (DC) and offers short-circuit protection for control voltage (AC), adhering to an IP20 communication protocol. The rated insulation voltage (Ui) is 12 mm, and it is designed for mounting on a DIN-35 rail. The unit measures H100mm x W12mm x D69mm and is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing. It features 8 digital outputs (24Vdc / 500mA) with high-side switching and supports 2-wire analog inputs. The module is capable of a 1kHz switching frequency and exhibits vibration resistance according to EN 60068-2-6 (4g) and shock resistance according to EN 60068-2-27 (15g). It has a resistance of 20mA (5Vdc, system supply) and 15mA (field supply, no external load) with a climatic resistance of 95% relative humidity (RH, non-condensing).

WAGOSTOCK: 14

This item can ship within 24h!

756-5401/060-150

WAGO - 756-5401/060-150

WAGOSTOCK: 50

This item can ship within 24h!

756-5401/050-050

WAGO 756-5401/050-050 is an automation part with an operating voltage of 250 VAC/DC and an operating current of 4A. It has a rated surge voltage of 1.5kV and an insulation resistance greater than 10^9Ω. The contact resistance is specified at 10mΩ, and the conductor resistance is less than or equal to 60Ω. This part is designed for environments with a pollution degree of 3 per VDE 0110 and offers protection type IP67, making it suitable for use in conditions with ambient (operating) temperatures ranging from -50 to +90°C statically and -25 to +90°C dynamically. It is compatible with drag chains, featuring a minimum bending radius of 10 times the cable diameter, 2 million bending cycles, a minimum acceleration of 5, a maximum travel speed of 3.33, and maximum travel paths of 5 meters horizontally and 2 meters vertically. The torsional capacity is 180. The cable, measuring 5 meters in length, is made of bare copper wire (fine-stranded 42 x 0.1mm) with PP9Y (halogen-free) conductor insulation and a polyurethane (PUR) sheath that is halogen-free per DIN VDE 0472 Part 815, flame resistant per IEC 332-2, and self-extinguishing. The sheathed cable is black, with a diameter of 4.8 to 5.2mm. Connection is facilitated through an M12 socket to M12 plug, with a 5-pole number and A-coded connector interface coding. The housing and contact materials are made of polyurethane (PUR) and CuSn, respectively, with a tightening torque of 1Nm. This product is categorized under Product Group 23 (I/O passive and accessories), with a packaging unit of 10 pieces per box and a country of origin in Hungary. It has a GTIN of 4055143060967 and a customs tariff number of 85444290900. It complies with RoHS, indicating no exemption from environmental product compliance standards.

WAGOSTOCK: 50

This item can ship within 24h!

750-602

Wago 750-602 is a power supply unit designed for I.O. power supply module applications. It operates on a supply voltage range of 18-31.2Vdc, with a nominal voltage of 24Vdc, and does not require an AC supply voltage. This unit can handle a rated current of 10A and is equipped with CAGE-CLAMP spring connections for secure and reliable connectivity. It is designed to operate within an ambient air temperature range of 0°C to +55°C and can be stored in temperatures ranging from -25°C to +85°C. The 750-602 features an IP20 degree of protection and is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing, ensuring durability. It has a rated insulation voltage (Ui) of 12 mm and is designed for mounting on a DIN-35 rail, with dimensions of H100mm x W12mm x D69.8mm. This unit is also characterized by its vibration resistance according to EN 60068-2-6 -- 4g and shock resistance according to EN 60068-2-27 -- 15g, making it suitable for environments with high levels of mechanical stress. It can operate in up to 95% relative humidity (non-condensing), ensuring performance in various operating conditions.

WAGOSTOCK: 16

This item can ship within 24h!

750-600

Wago 750-600 is a mounting accessory designed as an end module with a primary function to ensure the termination of a bus or power supply module within a system. It operates at a supply voltage of AC 0° and is suitable for ambient air temperatures ranging from -25°C to +55°C during operation and can be stored in temperatures from -25°C to +85°C. This part is designed to withstand vibration resistance according to EN 60068-2-6 standards at 4g and shock resistance according to EN 60068-2-27 standards at 15g, ensuring durability in challenging environments. It features an IP20 degree of protection and is compatible with a DIN-35 rail for mounting. The 750-600 has a rated insulation voltage (Ui) of 12 mm and is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing, measuring H100mm x W12mm x D69.8mm. It is designed to operate within environments with up to 95% relative humidity (non-condensing). The connection capacity and coating material are tailored to meet the specific requirements of automation systems, ensuring compatibility and performance.

WAGOSTOCK: 11

This item can ship within 24h!

750-1405

Wago 750-1405 is an I/O unit functioning as a standard DC digital input slice module. It operates with a supply voltage of 5Vdc provided by the system and an adjustable supply voltage of 18-32.5Vdc to field sensing devices. This unit features push-in spring cage-clamp connections and is designed for use in environments with an ambient air temperature range for operation from -25°C to +55°C and for storage from -40°C to +85°C. It supports a control voltage of 24Vdc with high-side switching and offers 16 digital inputs. The 750-1405 has an IP20 degree of protection and is mounted on a DIN-35 rail. Its housing is made of polycarbonate (PC) and polyamide (PA) 6.6, ensuring durability. The unit's digital inputs voltage ranges from -3 to +5Vdc (OFF) and 15-30Vdc (ON), with a trip current rating of 25mA at 5Vdc system supply. It features a vibration resistance according to EN 60068-2-6 of 4g and a shock resistance according to EN 60068-2-27 of 15g. The module is designed to withstand 95% relative humidity (non-condensing) and has a response time of 3ms with a filter. Its dimensions are H100mm x W12mm x D69mm, making it compact for efficient use of space.

WAGOSTOCK: 19

This item can ship within 24h!

750-1504

Wago 750-1504 is an I/O unit functioning as a standard DC digital output slice module. It operates with a supply voltage of 5Vdc provided by the system and an adjustable 18-32.5Vdc supply to field sensing devices. This unit features push-in spring cage-clamp connections and is designed for use in environments with an ambient air temperature range for operation from -25°C to +55°C and for storage from -40°C to +85°C. It supports a control voltage (DC) and offers short-circuit protection for control voltage (AC), with a degree of protection rated at IP20. The rated insulation voltage (Ui) is 12 mm, and the unit is designed for mounting on a DIN-35 rail. It has dimensions of H100mm x W12mm x D69mm and is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing. The module features 16 digital outputs (24Vdc / 500mA) with high-side switching and includes 1-wire analog inputs. It has a power dissipation/losses with vibration resistance according to EN 60068-2-6 -- 4g and shock resistance according to EN 60068-2-27 --15g. The unit consumes 40mA (5Vdc from the system supply) and 29mA (from the field supply with no external load). It is designed to operate within a climatic resistance of 95% relative humidity (RH), non-condensing.

WAGOSTOCK: 16

This item can ship within 24h!

750-1415

Wago 750-1415 is an I/O unit functioning as a standard DC digital input slice module. It operates with a supply voltage of 5Vdc provided by the system and an adjustable 18-32.5Vdc for field sensing devices. This unit features push-in spring cage-clamp connections and is designed for use in environments with an ambient air temperature ranging from -40°C to +55°C for operation and -40°C to +85°C for storage. It supports a control voltage of 24Vdc and utilizes an IP20 communication protocol. The rated insulation voltage is 12mm, and it is designed for mounting on a DIN-35 rail. The unit's dimensions are H100mm x W12mm x D69mm, and it is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing. It has 8 digital inputs with a 24Vdc transistor output and supports type-3 high-side switching. The digital inputs voltage ranges from -3 to +5Vdc (OFF) and 11-30Vdc (ON), with a trip current rating of 6mA for system supply and 2mA for field supply. It features a 3ms filter for digital inputs, vibration resistance according to EN 60068-2-6 at 4g, and shock resistance according to EN 60068-2-27 at 15g. The unit is designed to withstand up to 95% relative humidity (RH), non-condensing.

WAGOSTOCK: 18

This item can ship within 24h!

750-1515

Wago 750-1515 is an I/O unit functioning as a standard DC digital output slice module. It operates with a supply voltage of 5Vdc provided by the system and an adjustable supply to field sensing devices ranging from 18-32.5Vdc. This unit features push-in spring cage-clamp connections and is designed for operation in ambient air temperatures ranging from -40°C to +55°C, with storage temperatures from -40°C to +85°C. It supports a control voltage (DC) and offers short-circuit protection for control voltage (AC), adhering to an IP20 communication protocol. The rated insulation voltage (Ui) is 12 mm, and it is designed for mounting on a DIN-35 rail. The unit measures H100mm x W12mm x D69mm and is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing. It features 8 digital outputs (24Vdc / 500mA) with high-side switching and supports 2-wire analog inputs. The module is capable of a 1kHz switching frequency and exhibits vibration resistance according to EN 60068-2-6 (4g) and shock resistance according to EN 60068-2-27 (15g). It has a resistance of 20mA (5Vdc, system supply) and 15mA (field supply, no external load) with a climatic resistance of 95% relative humidity (RH, non-condensing).

WAGOSTOCK: 14

This item can ship within 24h!

756-5401/060-150

WAGO - 756-5401/060-150

WAGOSTOCK: 50

This item can ship within 24h!

756-5401/050-050

WAGO 756-5401/050-050 is an automation part with an operating voltage of 250 VAC/DC and an operating current of 4A. It has a rated surge voltage of 1.5kV and an insulation resistance greater than 10^9Ω. The contact resistance is specified at 10mΩ, and the conductor resistance is less than or equal to 60Ω. This part is designed for environments with a pollution degree of 3 per VDE 0110 and offers protection type IP67, making it suitable for use in conditions with ambient (operating) temperatures ranging from -50 to +90°C statically and -25 to +90°C dynamically. It is compatible with drag chains, featuring a minimum bending radius of 10 times the cable diameter, 2 million bending cycles, a minimum acceleration of 5, a maximum travel speed of 3.33, and maximum travel paths of 5 meters horizontally and 2 meters vertically. The torsional capacity is 180. The cable, measuring 5 meters in length, is made of bare copper wire (fine-stranded 42 x 0.1mm) with PP9Y (halogen-free) conductor insulation and a polyurethane (PUR) sheath that is halogen-free per DIN VDE 0472 Part 815, flame resistant per IEC 332-2, and self-extinguishing. The sheathed cable is black, with a diameter of 4.8 to 5.2mm. Connection is facilitated through an M12 socket to M12 plug, with a 5-pole number and A-coded connector interface coding. The housing and contact materials are made of polyurethane (PUR) and CuSn, respectively, with a tightening torque of 1Nm. This product is categorized under Product Group 23 (I/O passive and accessories), with a packaging unit of 10 pieces per box and a country of origin in Hungary. It has a GTIN of 4055143060967 and a customs tariff number of 85444290900. It complies with RoHS, indicating no exemption from environmental product compliance standards.

WAGOSTOCK: 50

This item can ship within 24h!

750-602

Wago 750-602 is a power supply unit designed for I.O. power supply module applications. It operates on a supply voltage range of 18-31.2Vdc, with a nominal voltage of 24Vdc, and does not require an AC supply voltage. This unit can handle a rated current of 10A and is equipped with CAGE-CLAMP spring connections for secure and reliable connectivity. It is designed to operate within an ambient air temperature range of 0°C to +55°C and can be stored in temperatures ranging from -25°C to +85°C. The 750-602 features an IP20 degree of protection and is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing, ensuring durability. It has a rated insulation voltage (Ui) of 12 mm and is designed for mounting on a DIN-35 rail, with dimensions of H100mm x W12mm x D69.8mm. This unit is also characterized by its vibration resistance according to EN 60068-2-6 -- 4g and shock resistance according to EN 60068-2-27 -- 15g, making it suitable for environments with high levels of mechanical stress. It can operate in up to 95% relative humidity (non-condensing), ensuring performance in various operating conditions.

WAGOSTOCK: 16

This item can ship within 24h!

750-600

Wago 750-600 is a mounting accessory designed as an end module with a primary function to ensure the termination of a bus or power supply module within a system. It operates at a supply voltage of AC 0° and is suitable for ambient air temperatures ranging from -25°C to +55°C during operation and can be stored in temperatures from -25°C to +85°C. This part is designed to withstand vibration resistance according to EN 60068-2-6 standards at 4g and shock resistance according to EN 60068-2-27 standards at 15g, ensuring durability in challenging environments. It features an IP20 degree of protection and is compatible with a DIN-35 rail for mounting. The 750-600 has a rated insulation voltage (Ui) of 12 mm and is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing, measuring H100mm x W12mm x D69.8mm. It is designed to operate within environments with up to 95% relative humidity (non-condensing). The connection capacity and coating material are tailored to meet the specific requirements of automation systems, ensuring compatibility and performance.

WAGOSTOCK: 11

This item can ship within 24h!

750-1405

Wago 750-1405 is an I/O unit functioning as a standard DC digital input slice module. It operates with a supply voltage of 5Vdc provided by the system and an adjustable supply voltage of 18-32.5Vdc to field sensing devices. This unit features push-in spring cage-clamp connections and is designed for use in environments with an ambient air temperature range for operation from -25°C to +55°C and for storage from -40°C to +85°C. It supports a control voltage of 24Vdc with high-side switching and offers 16 digital inputs. The 750-1405 has an IP20 degree of protection and is mounted on a DIN-35 rail. Its housing is made of polycarbonate (PC) and polyamide (PA) 6.6, ensuring durability. The unit's digital inputs voltage ranges from -3 to +5Vdc (OFF) and 15-30Vdc (ON), with a trip current rating of 25mA at 5Vdc system supply. It features a vibration resistance according to EN 60068-2-6 of 4g and a shock resistance according to EN 60068-2-27 of 15g. The module is designed to withstand 95% relative humidity (non-condensing) and has a response time of 3ms with a filter. Its dimensions are H100mm x W12mm x D69mm, making it compact for efficient use of space.

WAGOSTOCK: 19

This item can ship within 24h!

750-1504

Wago 750-1504 is an I/O unit functioning as a standard DC digital output slice module. It operates with a supply voltage of 5Vdc provided by the system and an adjustable 18-32.5Vdc supply to field sensing devices. This unit features push-in spring cage-clamp connections and is designed for use in environments with an ambient air temperature range for operation from -25°C to +55°C and for storage from -40°C to +85°C. It supports a control voltage (DC) and offers short-circuit protection for control voltage (AC), with a degree of protection rated at IP20. The rated insulation voltage (Ui) is 12 mm, and the unit is designed for mounting on a DIN-35 rail. It has dimensions of H100mm x W12mm x D69mm and is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing. The module features 16 digital outputs (24Vdc / 500mA) with high-side switching and includes 1-wire analog inputs. It has a power dissipation/losses with vibration resistance according to EN 60068-2-6 -- 4g and shock resistance according to EN 60068-2-27 --15g. The unit consumes 40mA (5Vdc from the system supply) and 29mA (from the field supply with no external load). It is designed to operate within a climatic resistance of 95% relative humidity (RH), non-condensing.

WAGOSTOCK: 16

This item can ship within 24h!

750-1415

Wago 750-1415 is an I/O unit functioning as a standard DC digital input slice module. It operates with a supply voltage of 5Vdc provided by the system and an adjustable 18-32.5Vdc for field sensing devices. This unit features push-in spring cage-clamp connections and is designed for use in environments with an ambient air temperature ranging from -40°C to +55°C for operation and -40°C to +85°C for storage. It supports a control voltage of 24Vdc and utilizes an IP20 communication protocol. The rated insulation voltage is 12mm, and it is designed for mounting on a DIN-35 rail. The unit's dimensions are H100mm x W12mm x D69mm, and it is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing. It has 8 digital inputs with a 24Vdc transistor output and supports type-3 high-side switching. The digital inputs voltage ranges from -3 to +5Vdc (OFF) and 11-30Vdc (ON), with a trip current rating of 6mA for system supply and 2mA for field supply. It features a 3ms filter for digital inputs, vibration resistance according to EN 60068-2-6 at 4g, and shock resistance according to EN 60068-2-27 at 15g. The unit is designed to withstand up to 95% relative humidity (RH), non-condensing.

WAGOSTOCK: 18

This item can ship within 24h!

750-1515

Wago 750-1515 is an I/O unit functioning as a standard DC digital output slice module. It operates with a supply voltage of 5Vdc provided by the system and an adjustable supply to field sensing devices ranging from 18-32.5Vdc. This unit features push-in spring cage-clamp connections and is designed for operation in ambient air temperatures ranging from -40°C to +55°C, with storage temperatures from -40°C to +85°C. It supports a control voltage (DC) and offers short-circuit protection for control voltage (AC), adhering to an IP20 communication protocol. The rated insulation voltage (Ui) is 12 mm, and it is designed for mounting on a DIN-35 rail. The unit measures H100mm x W12mm x D69mm and is housed in a polycarbonate (PC) / Polyamide (PA) 6.6 casing. It features 8 digital outputs (24Vdc / 500mA) with high-side switching and supports 2-wire analog inputs. The module is capable of a 1kHz switching frequency and exhibits vibration resistance according to EN 60068-2-6 (4g) and shock resistance according to EN 60068-2-27 (15g). It has a resistance of 20mA (5Vdc, system supply) and 15mA (field supply, no external load) with a climatic resistance of 95% relative humidity (RH, non-condensing).

WAGOSTOCK: 14

753-110

This part can ship within 24 hours

$5.29

$5.29
