Turck RI360P2-QR14-ELIU5X2-0.3-RS4T/BLC is a contactless rotary inductive angle sensor designed for precise angle measurement. It operates within an ambient air temperature range of -25 to +70°C and features a blind hole shaft with increased resolution, making it suitable for washdown environments. This sensor is pre-wired with a 30cm pigtail that terminates with a 3-pin M12 Eurofast QD connector, aligning with the Q-track QR14 series specifications. It has dimensions of H49mm x W54mm x D14mm and offers a degree of protection rated at IP68 and IP69K. The supply voltage requirement is 15Vdc to 30Vdc, with a nominal 24Vdc. Its rectangular shape is constructed from a plastic PBT-GF30-V0 housing, and it includes a 1/4" bore size. The sensor features protection against short-circuit, wire-break, and reverse polarity incidents. It provides one analog output (0-10Vdc / 4-20mA; 16-bit resolution) with a resolution of ≤0.09° / 12-bit and a measurement accuracy of ≤0.025% of full scale. The current consumption is 100mA, and it can measure angular positions from 0° to +360°. The sensor's functionality is enhanced with a green LED for multifunctional visual position indication and power status.
