SR2B201JD Schneider Electric Industrial Automation Components

SR2B201JD on Powermatic Associates
Schneider Electric

Part#:SR2B201JD

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric SR2B201JD is a compact smart/programmable control unit within the SR2 sub-range, designed for DIN rail mounting. It features 20 I/Os with 8 contact outputs and operates within an ambient air temperature range of -20 to +55 °C. The unit has a memory capacity of 120 lines for ladder programming and 200 lines for FBD programming. It offers a degree of protection of IP40 for the front panel and IP20 for the terminal block. The SR2B201JD consumes 0.2 A without extension and includes protection functions such as reverse polarity and program memory check on each power-up. It is equipped with 6 common mode analog inputs and operates on a 12 V DC supply voltage. The terminals are screw-clamp type, and the unit boasts an electrical durability of 500,000 operations and a mechanical durability of 10,000,000 operations at no load. Processing time ranges from 6 to 90 ms, with an operating rate of 36,000 cycles/hour at no load and 360 cycles/hour at Ie. The control unit also features an LCD display and performs a program memory measurement function on each power-up.

Product Details

  • Electrical Durability
    AC-12 500000 cycles 230 V, 1.5 A relay output EN/IEC 60947-5-1 AC-15 500000 cycles 230 V, 0.9 A relay output EN/IEC 60947-5-1 DC-12 500000 cycles 24 V, 1.5 A relay output EN/IEC 60947-5-1 DC-13 500000 cycles 24 V, 0.6 A relay output EN/IEC
  • Input Impedance
    14 kOhm IB...IG used as analogue input circuit 14 kOhm IB...IG used as discrete input circuit 2.7 kOhm I1...IA and IH...IR discrete input circuit
  • Analogue Input Range
    0...10 V 0...12 V
  • Response Time
    10 ms (from state 0 to state 1) for relay output 5 ms (from state 1 to state 0) for relay output
  • Current State 0 Guaranteed
    <= 0.9 mA I1...IA and IH...IR discrete input circuit) <= 0.9 mA IB...IG used as discrete input circuit)
  • Voltage State 1 Guaranteed
    >= 7 V IB...IG used as discrete input circuit >= 5.6 V I1...IA and IH...IR discrete input circuit
  • Conversion Error
    +/- 5 % 77 °F (25 °C) analogue input circuit +/- 6.2 % 131 °F (55 °C) analogue input circuit
  • Output Voltage Limits
    24...250 V AC relay output) 5...30 V DC relay output)
  • Connections - Terminals
    Screw terminals, 1 x 0.2...1 x 2.5 mm² AWG 25...AWG 14) semi-solid Screw terminals, 1 x 0.2...1 x 2.5 mm² AWG 25...AWG 14) solid Screw terminals, 1 x 0.25...1 x 2.5 mm² AWG 24...AWG 14) flexible with cable end Screw terminals, 2 x 0.2...2 x
  • Clock Drift
    12 min/year 32…131 °F (0…55 °C) 6 s/month 77 °F (25 °C)
  • Number Or Control Scheme Lines
    0…240 ladder 0…500 FBD
  • Voltage State 0 Guaranteed
    <= 3 V IB...IG used as discrete input circuit <= 2.4 V I1...IA and IH...IR discrete input circuit
  • Current State 1 Guaranteed
    >= 2 mA I1...IA and IH...IR discrete input circuit) >= 0.5 mA IB...IG used as discrete input circuit)
  • Operating Rate In Hz
    0.1 Hz at Ie)relay output 10 Hz no load)relay output
  • Overvoltage Category
    III EN/IEC 60664-1
  • Net Weight
    0.84 lb(US) (0.38 kg)
  • Tightening Torque
    4.43 lbf.in (0.5 N.m)
  • [Uimp] Rated Impulse Withstand Voltage
    4 kV EN/IEC 60947-1 and EN/IEC 60664-1
  • Switching Capacity In Ma
    >= 10 mA 12 V relay output)
  • Number Of Outputs
    8 relay
  • Conversion Time
    Smart relay cycle time analogue input circuit
  • Maximum Permissible Voltage
    14.4 V analogue input circuit
  • Analogue Input Type
    Common mode
  • Input Compatibility
    3-wire proximity sensors PNP discrete input
  • Analogue Input Number
    6
  • Discrete Input Voltage
    12 V DC
  • Reverse Polarity Protection
    With
  • Power Dissipation In W
    2.5 W without extension
  • [Us] Rated Supply Voltage
    12 V DC
  • Mechanical Durability
    10000000 cycles relay output
  • Clock
    With
  • Output Thermal Current
    8 A for all 8 outputs relay output
  • Operating Distance
    10 m between stations, with screened cable (sensor not isolated) analogue input circuit
  • Contacts Type And Composition
    NO relay output
  • Repeat Accuracy
    +/- 2 % 131 °F (55 °C) analogue input circuit
  • LSB Value
    39 mV analogue input circuit
  • Analogue Input Resolution
    8 bits at maximum voltage
  • Counting Frequency
    1 kHz discrete input
  • Discrete Input Current
    4 mA
  • Discrete Input Type
    Resistive
  • Maximum Supply Current
    200 mA without extension)
  • Discrete Input Number
    12 EN/IEC 61131-2 type 1
  • Supply Voltage Limits
    10.4…14.4 V
  • Range Of Product
    Zelio Logic
  • Checks
    Program memory on each power up
  • Backup Time
    10 years 77 °F (25 °C)
  • Cycle Time
    6…90 ms
  • Local Display
    With
  • Product Or Component Type
    Compact smart relay

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
