HU661AWKVW Schneider Electric Electronic Components

Product Details

• Maximum Horse Power Rating
  10 hp 240 V at AC 50-60 Hz for 3 phase conforming to NEC 430.52 20 hp 480 V at AC 50-60 Hz for 3 phase conforming to NEC 430.52 30 hp 600 V at AC 50-60 Hz for 3 phase conforming to NEC 430.52
• Tightening Torque
  45 lbf.in (5.08 N.m) 0.02 in² (13.3 mm²) (AWG 6) 40 lbf.in (4.52 N.m) 0.01 in² (8.367 mm²) (AWG 8) 35 lbf.in (3.95 N.m) 0.00…0.01 in² (2.06…5.261 mm²) (AWG 14...AWG 10)
• Wire Size
  AWG 12...AWG 6 aluminium AWG 14...AWG 6 copper
• Net Weight
  30.86 lb(US) (14 kg)
• Height
  20.5 in (520.70 mm)
• Voltage Rating
  600 V AC/DC
• Depth
  6.8 in (172.72 mm)
• Width
  16.13 in (409.70 mm)
• Mounting Type
  Surface
• Wiring Configuration
  6-wire
• Enclosure Rating
  NEMA 3R/12
• Current Rating
  30 A
• Number Of Poles
  6
• Factory Installed Neutral
  None
• Phase
  3 phase
• Disconnect Type
  Non-fusible disconnect
• Device Application
  Heavy application
• Product
  Single Throw Safety Switch
• Duty Rating
  Heavy duty
