2172 Hubbell Electronic Components

Product Details

• Weight
  0.15 lb
• Industry Standard(s)
  Certified to CSA, C22.2, No. 42 File 285 ; Fed. Spec. W-C-596 ; NEMA® WD-6 Compliant ; UL Listed to UL498 File No. E2186
• Voltage Rating Description
  125 V
• Amperage Rating
  15 A
• Height
  1.15 in
• Dimensions
  3.28 in x 1.57 in x 1.15 in
• Performance
  Electrical - Current Interrupting - Certified for current interrupting at full rated current ; Electrical - Dielectric Voltage - Withstands 2,000V minimum ; Environmental - Flammability - UL 94V-2 ; Environmental - Operating Temperature - Maximum continuo
• Nema Rating
  5-15R
• Carton Quantity
  10
• Wire Size
  #14 AWG to #10 AWG
• Number Of Wires
  3-Wire
• Wattage
  1875 W
• Voltage Rating
  125 VAC
• Phase
  Single Phase
• Dielectric Strength
  Withstands 2,000V minimum
• Current Rating
  15 A
• Current / Amperage Rating
  15 A
• Connectivity
  Back and Side Wired Screw Terminals
• Width
  1.57 in
• Length
  3.28 in
Display Size
Standard Sized Product
Type
Duplex Receptacle
UPC
783585196657
Operating Temperature
Maximum continuous 75�C and minimum -40�C without Impact
OEM Brand Name
Hubbell Wiring Device-Kellems
Number Of Poles
2-Pole
Item Type
Style Line Decorator Duplex
Horsepower - Maximum
0.5
Application
Hubbell-Pro Heavy Duty Hospital Grade
