Name: UZK24.071
Brand: Puls

UF20.481

PULS UF20.481 is an Uninterruptible Power Supply (UPS) control module, part of the UF-series, designed as a bfr. module with capacitive storage and features a green status LED. It is housed in aluminium and utilizes spring-clamp connections for connectivity. This module measures W64mm x H124mm x D102mm and operates on a supply voltage range of 38.4Vdc to 60Vdc, with a nominal voltage of 48Vdc. It is rated for a current of 20A (bfr.) and is designed for DIN rail mounting. The UF20.481 can operate in ambient air temperatures ranging from -25 to +70°C and is suitable for DC networks. It includes a visual position indicator for Ready, Buffering, and Inhibit statuses. The module offers protection functions including output overvoltage protection, with typical protection at 58Vdc and a maximum of 60Vdc. Buffer modules can be connected in parallel to increase output ampacity or hold-up time. It provides a fixed output voltage of 48Vdc, boasts an efficiency of 0.99 at 48Vdc input, and offers a hold time of 15ms / 0.15s at a 20A load. Power dissipation/losses are 1.9 W at 24Vdc input with 0A output current. Ripple is specified as 250mVpp at 5A, 400mVpp at 10A, and 600mVpp at 20A, across a frequency range of 20Hz to 20MHz at 50Ω. Its electrical durability is rated at 161,000 hours at 40°C and 457,000 hours at 25°C in standby mode.

Puls

ML30.100

Verified stock: 2

PULS ML30.100 is a power supply unit designed for AC/DC conversion with a primary function to supply power. It supports DIN rail mounting for easy installation and operates within an ambient air temperature range of -10 to +70°C. This unit is designed according to NEC Class 2 standards, offering a rated current of 1.3A at 24Vdc, and utilizes spring-clamp connections for secure attachment. It accepts a wide range of supply voltages from 85Vac to 264Vac (covering standard voltages like 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at 47-63Hz, with a turn-ON voltage of 46Vac and a shutdown voltage of 44Vac) and also operates on DC supply voltages from 88Vdc to 375Vdc. The ML30.100 is housed in a PC/ABS blend, ensuring durability, and measures 45mm in width, 75mm in height, and 91mm in depth. It is compatible with single-phase (1AC) or DC networks, has a rated power of 30W, and provides an adjustable output voltage range of 24Vdc to 28Vdc with a 250mV turn-ON overshoot. The unit features protection functions including an NTC for input inrush current limiting, achieves an efficiency of 0.875 at 230Vac input, and has a maximum inrush current consumption of 17A at 120Vac input and 35A peak at 230Vac input. Power dissipation/losses are rated at 4.3W, and it maintains a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω.

Puls

SL5.100

Verified stock: 1

PULS SL5.100 is a power supply unit designed with an EMC filter and DC-OK relay contact output. This AC/DC power supply unit (PSU) / converter is capable of a power boost up to 6A and features screw-clamp connections for secure installation. It has dimensions of W64mm x H124mm x D102mm and supports a wide range of supply voltages including AC: 85Vac-132Vac / 176Vac-264Vac and DC: 300Vdc, with a rated current of 5A at 24Vdc. The SL5.100 is designed for DIN rail mounting and can operate in ambient air temperatures ranging from 0 to +70°C. It has a net width of 64 mm and consumes 2.6A (with a 115V input) or 1.4A (with a 230V input), with a maximum inrush of 15A at 264Vac input. This unit is suitable for single-phase (1AC) or DC networks and includes protection functions against output overvoltage, short-circuit, and overload without switching off. The output voltage is fixed at 24Vdc, with an efficiency of 0.9 at 230Vac input. The rated power is 120W, with a hold time of 37ms at 196Vac input, and power dissipation/losses of 13.3W at full output load with a 230Vac input. It also features a 100ms start-up delay and a 5-20ms rise time under nominal input with a constant full current load, and a ripple of 50mVpp at 20Hz to 20MHz.

Puls

ML30.106

Verified stock: 1

PULS ML30.106 is a dual output voltage single-phase power supply unit (PSU) and AC/DC-Converter designed for DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and is classified as NEC Class 2. This unit provides a rated current of 2.5A at 12Vdc with spring-clamp connections for ease of installation. It supports a wide supply voltage range from 85Vac to 264Vac (with nominal values including 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at 47-63Hz), featuring a 46Vac turn-ON voltage and a 44Vac shutdown voltage. Additionally, it can be powered by DC voltages ranging from 88Vdc to 375Vdc, with nominal values such as 100Vdc, 110Vdc, 120Vdc, 127Vdc, 200Vdc, 220Vdc, and 250Vdc. The ML30.106 has dimensions of W45mm x H75mm x D91mm and is housed in a PC/ABS blend. It is suitable for single-phase (1AC) or DC networks, has a net width of 45 mm, and offers a rated power of 36W. The output voltage is symmetrical +/-12Vdc to +/-15Vdc, adjustable with a 250mV turn-ON overshoot. It features protection functions including NTC for input inrush current limiting, achieves an efficiency of 0.86 with a 230Vac input, and has a current consumption of 17A max. inrush at 120Vac input and 35A peak max. inrush at 230Vac input. Power dissipation/losses are rated at 5.9 W, and it has a ripple of 50mVpp across 20Hz to 20MHz at 50Ω.

Puls

CP10.241-C1

Verified stock: 1

PULS CP10.241-C1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 39mm. The unit consumes 1.13A at 230Vac input, 2.15A at 120Vac input, 2.6A at 100Vac input, and 2.35A at 110Vdc input for a 24Vdc / 10A output, with peak inrush currents of 11A at 230Vac input and 7A at 120Vac input. It offers an efficiency of 0.952 at 230Vac input and 0.936 at 120Vac input. The CP10.241-C1 features IP20 degree of protection and is resistant to harsh environments due to its conformal coated PCB. Its dimensions are W39mm x H124mm x D117mm. The unit has a start-up delay of 240-300ms and a rise time of 30ms to 160ms depending on the load capacitance. It includes protection functions such as output overvoltage, overload/short-circuit, and over-temperature protection with automatic restart. The power supply supports series/parallel operation for increased output voltages or power, and 1+1 redundancy with a redundancy module. It can handle back-feeding loads up to 35V without malfunctioning. Power dissipation/losses are 12.1W at 230Vac input and 16.4W at 120Vac input, with an output stage capacitance of 4400µF. Electrical durability ranges from 39,000 to 499,000 hours depending on the operating conditions. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit is part of the CP-series, featuring ATEX approval, conformal coating, 20% power reserve, and a DC-OK relay contact output. It uses screw-clamp connections and accepts a supply voltage of 88Vdc-180Vdc or 85Vac-264Vac, with specific tolerances for overvoltage and shutdown voltages. The rated current is 12A at 48Vdc in temperatures up to +45°C, decreasing to 7.5A at 24Vdc at +70°C. It is suitable for single-phase (1AC) or DC networks, providing a rated power of 288W at -25 to +45°C, 240W at -25 to +60°C, and 180W at +70°C, with a linear derating between +60°C and +70°C. The output voltage is adjustable from 24Vdc to 28Vdc, with a 200mV turn-ON overshoot and a hold time of 37ms at 120/230Vac input.

Puls

UZK24.121

Verified stock: 0

PULS UZK24.121 is a battery module designed for 24Vdc systems, featuring a complete set including 2 batteries plus hardware. It has a capacity of 12Ah and provides an output voltage of 24Vdc. The dimensions of this product are W203mm x H186mm x D143mm, ensuring it fits into a variety of setups without requiring excessive space. It operates with a supply voltage of 24Vdc and is specifically designed to deliver 20A, catering to applications requiring a robust power solution.

Puls

UZK24.262

Verified stock: 0

PULS UZK24.262 is a complete battery module designed with ATEX approval, incorporating two batteries and the necessary hardware for operation. This module has dimensions of W359mm x H214mm x D167mm, operates with a supply voltage of 24Vdc, and offers a capacity of 26Ah. Its output voltage is also rated at 24Vdc.

Puls

UZK24.122

Verified stock: 0

PULS UZK24.122 is a battery module designed with ATEX approval, featuring a 24Vdc supply and output voltage, and a capacity of 12Ah. This complete battery module includes 2 batteries plus the necessary hardware for operation. It has dimensions of W203mm x H186mm x D125mm, ensuring it can be accommodated within a variety of settings. The design facilitates a 40A current, suitable for applications requiring a robust power supply solution.

Puls
