PV4-14R-E Panduit Electronic Components

Product Details

• Part Features
  • Ring tongue design assures a secure connection in high vibration applications • Insulation support helps to prevent wire damage in bending applications • Internal barrel serrations assure good wire contact and maximum tensile strength
• Packaging Type
  Bottle
• Tongue Width (In.)
  0.55
• Maximum Wire Insulation Diameter (mm)
  11.4
• Product Type
  Ring Terminal
• Tongue Thickness (mm)
  1.3
• Tongue Width (mm)
  13.9
• Tongue Thickness (In.)
  0.05
• Tongue Length (mm)
  27.4
• For Use With
  CT-720 (CD-720PV8-2); CT-2600 (CD-2600-PV4)
• Overall Width (mm)
  13.9
• Tongue Length (In.)
  1.08
• Overall Width (In.)
  0.55
• Outer Diameter (In.)
  0.45
• Overall Length (In.)
  1.88
• Sub Brand
  Pan-term
• Outer Diameter (mm)
  11.4
• Overall Length (mm)
  47.8
• Maximum Wire Insulation Diameter (In.)
  0.45
• Maximum Operating Temperature (°F)
  221
Maximum Operating Temperature (°C)
105
Insulation Diameter (mm)
11.4
Insulation Diameter (In.)
0.45
Flammability Rating
UL 94 V-0
Barrel Length (mm)
20.3
Barrel Length (In.)
0.8
Color Code
Yellow
Barrel Type
Funnel
Maximum Voltage (kV)
0.6
Maximum Voltage (V)
600
Finish/Coating
Tin-Plated
Standards Met
UL Listed 587H E52164
Base Material
Copper
Wire Strip Length (mm)
12.7
Wire Strip Length (In.)
0.50
Minimum Copper Conductor Size (AWG STR)
#4
Minimum Copper Conductor Size (AWG)
#4
Minimum Copper Conductor Size (AWG SOL)
#4
Maximum Copper Conductor Size (AWG)
#4
Maximum Copper Conductor Size (AWG STR)
#4
Maximum Wire Size (AWG)
#4
Minimum Wire Size (AWG)
#4
Maximum Copper Conductor Size (AWG SOL)
#4
Stud Hole Size (mm)
6.8
Insulation Material
Vinyl
Stud Size
1/4"
Stud Hole Size (In.)
27/100
