PNF14-8R-C Panduit Electronic Components

Product Details

• Product Type
  Ring Terminal
• Part Features
  • Ring tongue design assures a secure connection in high vibration applications • Metal insulation grip sleeve crimps to wire insulation, providing protection to the crimp joint during high vibration applications • Internal barrel serrations assure goo
• Tongue Length (mm)
  44.2
• Tongue Thickness (In.)
  0.32
• Tongue Width (In.)
  0.31
• Packaging Type
  Bottle
• Overall Width (mm)
  7.9
• Tongue Width (mm)
  7.9
• Tongue Length (In.)
  1.74
• Tongue Thickness (mm)
  8.1
• Overall Width (In.)
  0.31
• Overall Length (mm)
  22.1
• Minimum Wire Insulation Diameter (mm)
  2
• Minimum Wire Insulation Diameter (In.)
  0.08
• Maximum Wire Insulation Diameter (mm)
  4.1
• Maximum Wire Insulation Diameter (In.)
  0.16
• Overall Length (In.)
  0.87
• Sub Brand
  Pan-Term
• Outer Diameter (mm)
  6.4
• Outer Diameter (In.)
  0.25
Maximum Operating Temperature (°F)
221
Maximum Operating Temperature (°C)
105
Flammability Rating
UL 94 V-2/UL 94 HB
CSA Temperature Rating (°C)
221
Insulation Diameter (mm)
4.1
Barrel Length (mm)
44.2
Insulation Diameter (In.)
0.16
Barrel Length (In.)
1.74
Barrel Type
Grip Sleeve
Color Code
Blue
Finish/Coating
Tinned
Maximum Voltage (kV)
1
Maximum Voltage (V)
1000
Base Material
Copper
Minimum Copper Conductor Size (AWG)
16
Minimum Copper Conductor Size (AWG STR)
14
Minimum Copper Conductor Size (AWG SOL)
14
Wire Strip Length (mm)
5.5
Standards Met
UL Listed 587H E52164; CSA Certified LR31212
Wire Strip Length (In.)
0.21
Maximum Wire Size (AWG)
#14
Minimum Wire Size (AWG)
#16
Maximum Copper Conductor Size (AWG)
14
Maximum Copper Conductor Size (AWG SOL)
14
Maximum Copper Conductor Size (AWG STR)
14
Stud Hole Size (mm)
203.2
Insulation Material
Nylon
Minimum Operating Temperature (°C)
105
Stud Hole Size (In.)
8.00
Stud Size
#8
