YA28A5 Hubbell Industrial Automation Components

YA28A5 on Powermatic Associates
Hubbell

Part#:YA28A5

Manufacturer:Hubbell

Category:Industrial Automation Components

Product Lifecycle:Active

Only 4 left in stock. Order Now!

Mar 14, 2025

Product description

4/0 AWG, AL Terminal, Two Hole, 1/2" Stud Size, 1-3/4" Hole Spacing, AL9CU, Internal Chamfer, Tin Plated, Prefilled PENETROX™, End Cap, UL/CSA, 90°C, Up to 35kV, White Color Code, 298 Die Index ; UL Listed 90 DEG C, 600 V - 35 KV,Tongue Angle: Straight

Product Details

  • Conductor - AL Str Size Range
    4/0 AWG
  • Conductor - Copper Str Size
    4/0 AWG
  • Conductor - AL Str Size
    4/0 AWG
  • Voltage - Maximum
    35000
  • Rating - KVA
    35 kV
  • Voltage Rating
    35 kV
  • Dimension - Thread Size
    1/2
  • Physical Attribute - Tongue Angle
    Straight
  • Dimension - Stud Size inch
    1/2
  • Dimension - N inch
    0.63 in
  • Dimension - Stud Size fraction
    1/2"
  • Dimension - Z inch
    0.73 in
  • Dimension - Bolt Size fraction
    1/2
  • Dimension - Strip Length inch
    1-5/8
  • Dimension - Pad Width inch
    1.17 in
  • Dimension - Outside Diameter inch
    0.85 in
  • Dimension - L Length Overall mm
    132 mm
  • Dimension - B Length inch
    1.39 in
  • UPC 12 Digit
    7818107545044
  • Type
    YA-A
  • Trade Name
    HYLUG™
  • Sub Brand
    TERMINALS, HYLUG
  • Temperature Rating
    194
  • Die Index
    298
  • Feature - Barrel Type
    Standard
  • Physical Attribute - Number of Holes
    2
  • Feature - Barrel Style
    Chamfered
  • Physical Attribute - Tongue Type
    Standard
  • EU RoHS Indicator
    Yes
  • Color Code
    White
  • Minimum Pack Quantity
    1
  • UL Listed
    Yes
  • Standards - RoHS Compliance Status
    CM
  • Industry Standard(s)
    UL 486A-486B
  • Certification - cULus
    No
  • Standards - Industry Standards Met
    UL 486A-486B
  • Certification - ETL
    No
  • Certification - UL Recognized
    No
  • Conductor - Copper Str Size Range
    4/0 AWG
  • Certification - CSA Approved
    Yes
  • Wire Size
    4/0 AWG
  • Dimension - Length Overall inch
    5.19 in
  • Dimension - Hole Size inch
    0.56 in
  • Dimension - Hole Size mm
    14 mm
  • Dimension - D inch
    3.11 in
  • Dimension - B Length fraction
    1-3/8 in
  • Dimension - Bolt Hole Size inch
    0.52 in
  • UPC
    781810754504
  • Plated
    Y
  • Plating Type
    Tin - Electro Plated
  • Connector Type
    Terminal

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
