ABC4090-A HMS Networks Industrial Automation Components

Product Details

• PROFINET Configuration File
  GSDML available
• PROFINET Conformance Class
  Class B
• PROFINET Output Data Size
  1024 bytes
• PROFINET Input Data Size
  1024 bytes
• Modbus-TCP Output Data Size
  1500 bytes
• PROFINET Bandwidth
  10/100MBit down to 1ms cycle time
• PROFINET Mode
  Slave
• PROFINET Supported Functionality
  RT; Daisy chaining;
• Modbus-TCP Functions Supported
  1, 2, 3, 4, 5, 6, 15, 16, 23, 43/14
• Modbus-TCP Input Data Size
  1500 bytes
• Modbus-TCP Bandwidth
  10/100 Mbit/s
• EtherNet/IP Configuration File
  EDS available
• EtherNet/IP Output Data Size
  1448 bytes
• EtherCAT Output Data Size
  1486 bytes
• Modbus-TCP Mode
  Slave / Server
• Modbus-TCP Supported Functionality
  Modbus specification V1.1b3; 4 connections; Daisy chaining
• EtherNet/IP Bandwidth
  10/100MBit down to 1ms cycle time
• EtherNet/IP Input Data Size
  1448 bytes
• EtherNet/IP Mode
  Adapter / Slave
• EtherNet/IP Supported Functionality
  Endian conversion (byte swap); QoS; Ethernet/IP Class 1 and 3; Quick Connect Class B; DLR (beacon mode); Daisy Chainging; CT19 ODVA Conformance
EtherCAT Configuration File
ESI available
EtherCAT Input Data Size
1486 bytes
EtherCAT Bandwidth
10/100 Mbit down to 100us cycle time
EtherCAT Supported Functionality
COE (Can Over EtherCAT); PDO, SDO; APRD, ARMW, APWR, BRD, BWR, FPRD, FPRW, FPWR, FRMW, LRD, LRW, LWR
Export Control Classification Number (ECCN) (ERP)
5A991.b.1
Predecessor
AB7632-F, AB7682-F, AB7649-F, AB7901-F, AB7650-F, AB7684-F
Model Code
40-ETH-ETH-B
Country of Origin
Sweden
EtherCAT Mode
Slave / SubDevice
Dual Usage (ERP)
No
HS Code
8517620000
Push Buttons
Factory reset
Recycle / Disposal
Yes
DIP & Rotary Switches
Security lock switch
RoHS Compliant
Yes
Waste Certification (WEEE)
Yes
Protection Class IP
IP20, IP54
Contains Battery
No
WEEE Category
IT and telecommunications equipment
Connectors / Input / Output
2xRJ45;2x RJ45;RJ45 Config port
Environment
EN 55016-2-3 Class A, EN 55032 Class A, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
EMC
Yes
FCC
No
MTBF
Yes
ATEX Code
II 3 G Ex ec IIC T4 Gc, EN IEC 60079-0, 60079-7, IEC 60664-1
KC
Yes
ATEX
No
Warranty (years)
5
cUL
Yes
UL
Yes
CE
Yes
UL File Number
E214107: Ord.Loc UL 61010-1, CSA C22.2 No. 61010-1, UL 61010-2-201, CSA C22.2 No. 61010-2-201
Packaging Material
Cardboard
Housing Materials
PC ABS, UL 94 VO
Relative Humidity
0-95% Non-condensing.
Maximum Installation Altitude (m)
2000
Storage Temperature °C Max
85 °C
Storage Temperature °C Min
-40 °C
Operating Temperature °C Max
70 °C
Operating Temperature °C Min
-25 °C
Reverse Polarity Protection
Yes
Isolation
Yes
Short Circuit Protection
Yes
Power Connector
3-pin, 5.08 Phoenix plug connector
Net Width (ERP) (mm)
27 mm
Net Weight (ERP) (g)
150 g
Current Consumption Max value at Vcc nom (mA)
125mA @24V DC (3W)
Input Voltage (V)
12-30V DC
Current Consumption Type Value at Vcc Nom (mA)
90mA @ 24V DC (2.2W)
Net Height (ERP) (mm)
177 mm
Mounting
DIN-rail (EN 50022 standard)
Net Depth (ERP) (mm)
98 mm
Content of Delivery
Product, installation sheet, connectors
