AB7651-F HMS Networks Industrial Automation Components

Product Details

• PROFINET Configuration File
  GSDML available
• PROFINET Output Data Size
  512 bytes
• PROFINET Conformance Class
  Class B
• PROFINET Input Data Size
  512 bytes
• Export Control Classification Number (ECCN) (ERP)
  5A991.b.1
• PROFINET Bandwidth
  10/100Mbit full/half duplex down to 1ms
• PROFINET Supported Functionality
  Soft Real-Time (RT); Max 64 slots / 1 sub-slot; DCP support; Acyclic Data exchange
• Successor
  ABC4022-A, ABC4090-A
• PROFINET Mode
  Slave
• Country of Origin
  Sweden
• Dual Usage (ERP)
  No
• Connectors / Input / Output
  2x RJ45;USB-B Config port
• Contains Battery
  No
• HS Code
  8517620000
• RoHS Compliant
  Yes
• WEEE Category
  IT and telecommunications equipment
• Waste Certification (WEEE)
  Yes
• Environment
  EN 61000-6-4, EN 55016-2-3 Class A, EN 55022 Class A, EN 61000-6-2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
• FCC
  No
• Recycle / Disposal
  Yes
EMC
Yes
Protection Class IP
IP20
Operating Temperature °C Max
65 °C
Storage Temperature °C Max
85 °C
UL File Number
E214107: Ord.Loc UL508, CSA C22.2 NO. 142
CE
Yes
UL
Yes
Housing Materials
Aluminum, Plastic
Operating Temperature °C Min
-25 °C
Packaging Material
Cardboard
Short Circuit Protection
Yes
Isolation
Yes
Current Consumption Type Value at Vcc Nom (mA)
200mA @ 24V DC
Storage Temperature °C Min
-40 °C
Reverse Polarity Protection
Yes
Power Connector
2-pin, 5.08 Phoenix plug connector
Current Consumption Max value at Vcc nom (mA)
400mA @ 24V DC
Net Height (ERP) (mm)
127 mm
Input Voltage (V)
24V DC (-20% to +20%)
Net Weight (ERP) (g)
400 g
Net Width (ERP) (mm)
44 mm
Net Depth (ERP) (mm)
114 mm
Mounting
DIN-rail (EN 50022 standard)
Customs Tariff Number
8517620090
Primary brand
eWON by HMS Networks
Manufacturer description
Anybus X-Gateways - Network 1 PROFINET I/O Slave / Network 2 PROFINET I/O Slave
