8114752 Festo Pressure Sensors

Name: 8114752
Brand: Festo

Part#:8114752

Manufacturer:Festo

Alt. Part#:SPAN-B-V1R-G18M-PN-L1

Product Lifecycle:Active

Get a quick Quote!

Pressure sensor SPAN-B-V1R-G18M-PN-L1

About the manufacturer: Festo is one of the manufacturers that offers Pressure Sensors that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 8114752 Festo price in the box on the right side or send a quick quote.

Product Details

Electrical connection 1, connection type
Plug
Certification
RCM compliance mark
Measured variable
Relative pressure
Temperature of medium
0 °C ... 50 °C
Repetition accuracy in ± %FS
0.3 %FS
Reverse polarity protection
for all electrical connections
Pneumatic connection
External thread G1/8
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Electrical connection for input 1, connection pattern
00995428
CE marking (see declaration of conformity)
As per EU EMC directive As per EU RoHS directive
Max. overload pressure
5 bar
Accuracy in ± % FS
1.5 %FS
Switching function
Window comparator Threshold value comparator
DC operating voltage range
10.8 V ... 30 V
Product weight
31 g
Displayable unit(s)
MPa psi
Setting range hysteresis
0 % ... 90 %
Electrical connection 1, connection technology
Connection diagram L1J
Electrical connection 1, number of pins/wires
4
Overload pressure
72.5 psi

Method of measurement

Piezoresistive pressure sensor

Switching output

PNP/NPN switchable

Short-circuit protection

yes

Mounting position

Any

Display type

Illuminated LCD

Setting range threshold value

0 % ... 100 %

Pressure measuring range initial value

0 bar

Pressure measuring range end value

-1 bar

Operating medium

Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas

Ambient temperature

0 °C ... 50 °C

Max. output current

80 mA

Type of mounting

Front panel mounting With wall/surface bracket

Materials in contact with the media

FPM PA-reinforced

Setting options

Teach-in Via display and pushbuttons

Degree of protection

IP40

Type code

SPAN

KC characters

KC EMC

Symbol

00997331

Note on materials

RoHS-compliant

Information on operating and pilot media

Operation with oil lubrication possible

Temperature co-efficient in ± %FS/K

0.1 %FS/K

Switching element function

N/C contact/N/O contact switchable

Housing material

PA-reinforced

Protection against tampering

PIN code

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
