8114532 Festo Pneumatic Components

Product Details

• Max. contraction
  20 % of nominal length
• Permissible parallelism tolerance
  ±0.5 % up to a nominal length of 400 mm
• Permissible angle tolerance
  ≤ 1 deg
• Maximum additional load freely suspended
  5 kg
• Sleeve material
  Wrought aluminum alloy Plain anodized
• Stroke
  0 mm ... 200 mm
• Nominal length
  50 mm
• Type code
  DMSP
• Operating pressure
  0 bar ... 6 bar
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Note on materials
  Free of copper and PTFE RoHS-compliant
• Diameter expansion at max. contraction
  12 mm
• Muscle repetition accuracy
  <= 1 % of nominal length, cyclic
• Mounting position
  Any
• Mode of operation
  Single-acting Pulling
• Certification
  German Technical Control Board (TÜV)
• Material of flange
  Wrought aluminum alloy Plain anodized
• Symbol
  00991121
• Information on operating and pilot media
  Operation with oil lubrication possible (required for further use)
• Pneumatic connection
  M3
Theoretical force Fluidic Muscle at maximum operating pressure
140 N
Diaphragm material
AR CR
Size
5
Max. pre-tensioning
1 % of nominal length
Design
Contracting diaphragm
Operating medium
Compressed air as per ISO 8573-1:2010 [7:-:-]
Ambient temperature
-5 °C ... 60 °C
Theoretical force at 6 bar
140 N
Nut material
Steel Galvanized
