8001220 Festo Pressure Sensors

Product Details

• Electrical connection 1, connection technology
  M12x1 A-coded as per EN 61076-2-101
• Symbol
  00995410
• Pressure measuring range initial value
  0 bar
• ADC resolution
  12 bit
• Switching element function
  N/C contact/N/O contact switchable
• Max. load resistance of current output
  500 Ohm
• IO-Link®, profile
  Smart sensor profile
• IO-Link®, SIO mode support
  Yes
• Type of mounting
  With H-rail
• Display type
  Illuminated LCD
• Protection against tampering
  IO-Link® PIN code
• Type code
  SPAU
• KC characters
  KC EMC
• CE marking (see declaration of conformity)
  As per EU EMC directive As per EU RoHS directive
• Measured variable
  Relative pressure
• Max. overload pressure
  15 bar
• Information on operating and pilot media
  Operation with oil lubrication possible
• Repetition accuracy in ± %FS
  0.3 %FS
• Analog output
  0 - 10 V 1 - 5 V
• Short-circuit protection
  yes
IO-Link®, port class
A
IO-Link®, minimum cycle time
3 ms
DC operating voltage range
20 V ... 30 V
Setting options
IO-Link® Via display and pushbuttons
Degree of protection
IP65 IP67
Certification
RCM compliance mark c UL us - Listed (OL)
Pressure measuring range end value
10 bar
Ambient temperature
0 °C ... 50 °C
Switching output
2 x PNP or 2 x NPN switchable
Switching function
Freely programmable
Protocol
IO-Link®
IO-Link®, communication mode
COM2 (38,4 kBd)
IO-Link®, data memory required
500 byte
Mounting position
Any
Displayable unit(s)
MPa psi
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Electrical connection 1, connection type
Plug
Note on materials
RoHS-compliant
Temperature of medium
0 °C ... 50 °C
Temperature co-efficient in ± %FS/K
0.05 %FS/K
Min. load resistance of voltage output
10 kOhm
IO-Link®, protocol version
Device V 1.1
IO-Link®, process data width IN
2 Byte
Reverse polarity protection
for all electrical connections
Pneumatic connection
G1/8
Setting range hysteresis
0 % ... 90 %
Electrical connection for input 1, connection pattern
00995386
Electrical connection 1, number of pins/wires
4
Method of measurement
Piezoresistive pressure sensor
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
Accuracy in ± % FS
1.5 %FS
Max. output current
100 mA
Rise time
3 ms
IO-Link®, function classes
Binary data channel (BDC) Teach channel
IO-Link®, process data width OUT
0 Byte
IO-Link®, process data content IN
14 bit PDV (pressure measurement) 2 bit BDC (pressure monitoring)
Product weight
70 g
Setting range threshold value
0 % ... 100 %
