8001233 Festo Pressure Sensors

Product Details

• Type code
  SPAU
• Electrical connection 1, connection type
  Plug
• Certification
  RCM compliance mark c UL us - Listed (OL)
• Information on operating and pilot media
  Operation with oil lubrication possible
• ADC resolution
  12 bit
• Switching element function
  N/C contact/N/O contact switchable
• Min. load resistance of voltage output
  10 kOhm
• IO-Link®, protocol version
  Device V 1.1
• IO-Link®, function classes
  Binary data channel (BDC) Teach channel
• IO-Link®, minimum cycle time
  3 ms
• KC characters
  KC EMC
• Note on materials
  RoHS-compliant
• CE marking (see declaration of conformity)
  As per EU EMC directive As per EU RoHS directive
• Electrical connection 1, connection technology
  M8x1 A-coded as per EN 61076-2-104
• Electrical connection 1, number of pins/wires
  4
• Measured variable
  Relative pressure
• Max. overload pressure
  15 bar
• Temperature of medium
  0 °C ... 50 °C
• Switching function
  Freely programmable
• Max. load resistance of current output
  500 Ohm
IO-Link®, profile
Smart sensor profile
IO-Link®, process data width IN
2 Byte
IO-Link®, data memory required
500 byte
Product weight
70 g
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Electrical connection for input 1, connection pattern
00991171
Symbol
00995410
Method of measurement
Piezoresistive pressure sensor
Pressure measuring range end value
6 bar
Accuracy in ± % FS
1.5 %FS
Switching output
2 x PNP or 2 x NPN switchable
Rise time
3 ms
Short-circuit protection
yes
IO-Link®, port class
A
DC operating voltage range
20 V ... 30 V
Pneumatic connection
G1/8
Displayable unit(s)
MPa psi
Pressure measuring range initial value
0 bar
Repetition accuracy in ± %FS
0.3 %FS
Max. output current
100 mA
IO-Link®, communication mode
COM2 (38,4 kBd)
IO-Link®, process data width OUT
0 Byte
Mounting position
Any
Protection against tampering
IO-Link® PIN code
Setting range hysteresis
0 % ... 90 %
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
Ambient temperature
0 °C ... 50 °C
Temperature co-efficient in ± %FS/K
0.05 %FS/K
Analog output
0 - 10 V 1 - 5 V
Protocol
IO-Link®
IO-Link®, SIO mode support
Yes
IO-Link®, process data content IN
14 bit PDV (pressure measurement) 2 bit BDC (pressure monitoring)
Reverse polarity protection
for all electrical connections
Display type
Illuminated LCD
Setting options
IO-Link® Via display and pushbuttons
Type of mounting
With wall/surface bracket
Setting range threshold value
0 % ... 100 %
Degree of protection
IP65 IP67
