7862 Festo Pneumatic Components

7862 on Powermatic Associates
Festo

Part#:7862

Alt. Part#:PE-1/8-2N-SW

Manufacturer:Festo

Category:Pneumatic Components

Product Lifecycle:Active

Product description

PE converter PE-1/8-2N-SW Pneumatic/electrical signal converter. Authorisation: CCC, CE mark (see declaration of conformity): to EU directive low-voltage devices, Measured variable: Relative pressure, Measurement method: Pneu./elect. pressure transducer,

Product Details

  • Type code
    PE
  • CE marking (see declaration of conformity)
    As per EU low voltage directive
  • Temperature of medium
    0 °C ... 60 °C
  • Switching element function
    Changeover switch
  • Electrical connection
    3 connecting wires
  • Pneumatic connection
    G1/8
  • Certification
    CCC
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Min. switch-off point
    0.5 bar
  • DC operating voltage range
    12 V ... 250 V
  • Cable length
    0.5 m
  • Electrical connection material
    Tin-plated
  • Degree of protection
    IP67
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Switching function
    Threshold value with fixed hysteresis
  • Max. switch-on point
    2 bar
  • Mounting position
    Any
  • Type of mounting
    Optionally: With through-hole
  • Switching contact material
    Silver
  • Symbol
    00995409
  • Method of measurement
    Pneumatic/electric pressure transducer
  • Switching output
    Contact-based
  • Operating voltage range AC
    12 V ... 250 V
  • Material of cable sheath
    PVC
  • Housing material
    Die-cast aluminum VMQ (silicone)
  • Operating pressure
    0 bar ... 8 bar
  • Measured variable
    Relative pressure
  • Ambient temperature
    0 °C ... 60 °C
  • Minimum load current
    100 mA
  • Max. switching frequency
    1 Hz
  • Product weight
    65 g
  • Diaphragm material
    TPE-U(PU)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
