534682 Festo Pneumatic Components

534682 on Powermatic Associates
Festo

Part#:534682

Alt. Part#:GR-QB-1/4-U

Manufacturer:Festo

Category:Pneumatic Components

Product Lifecycle:Active

Only 5 left in stock. Order Now!

Apr 22, 2025

Product description

one-way flow control valve GR-QB-1/4-U Valve function: One-way flow control function, Pneumatic connection, port 1: QB-1/4, Pneumatic connection, port 2: QB-1/4, Type of actuation: manual, Adjusting element: Slotted head screw

Product Details

  • Standard flow rate in non-return direction at 6 -> 0 bar
    1347.458 l/min ... 1360.169 l/min
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Seals material
    NBR
  • Valve function
    Flow control non-return function
  • Actuation type
    Manual
  • Operating pressure
    -0.951 bar ... 7.998 bar
  • Mounting position
    Any
  • Material of screwed trunnion
    Brass Nickel-plated
  • Knurled head material
    Brass Nickel-plated
  • Type code
    GR
  • Pneumatic connection 2
    QB-1/4
  • Ambient temperature
    0 °C ... 60 °C
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant
  • Pneumatic connection 1
    QB-1/4
  • Adjusting element
    Slotted screw
  • Standard nominal flow rate in non-return direction
    635.593 l/min ... 699.153 l/min
  • Housing material
    PBT-reinforced
  • Symbol
    00991453
  • Temperature of medium
    0 °C ... 60 °C
  • Material of adjusting screw
    Brass Nickel-plated
  • Standard nominal flow rate in flow control direction
    597.46 l/min
  • Type of mounting
    Optionally: With through-hole
  • Standard flow rate in flow control direction 6 -> 0 bar
    991.5 l/min
  • Product weight
    28.35 g
  • Releasing ring material
    POM

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
