564646 Festo Pneumatic Fittings

564646 on Powermatic Associates
Festo

Part#:564646

Alt. Part#:QBF-1/4-3/8-U

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

8 in stock

Apr 26, 2025

Product description

push-in fitting QBF-1/4-3/8-U female thread with external hexagon. Size: Standard, Nominal size: 0,315 ", Type of seal on screw-in stud: coating, Assembly position: Any, Design structure: Push/pull principle

Product Details

  • Type of seal on screwed trunnion
    Coating
  • Operating pressure for entire temperature range
    -0.951 bar ... 9.997 bar
  • Ambient temperature
    0 °C ... 60 °C
  • Pneumatic connection 1
    Internal thread 1/4 NPT
  • Housing material
    Brass, nickel-plated
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Pneumatic connection 2
    for pneumatic tubing outside diameter 3/8"
  • Material of threaded seal
    PTFE
  • Nominal width
    8.001 mm
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Max. tightening torque
    12 Nm
  • Material of tubing seal
    NBR
  • Size
    Standard
  • Mounting position
    Any
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Releasing ring color
    Gray
  • Material of tube retaining claw
    High-alloy stainless steel
  • Type code
    QBF
  • Design
    Push-pull principle
  • Temperature-dependent operating pressure
    -0.951 bar ... 9.997 bar
  • Product weight
    26.394 g
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant
  • Releasing ring material
    POM

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
