559265 Festo Pneumatic Actuators
Part#:559265
Alt. Part#:DSNU-16-50-PPS-A
Manufacturer:Festo
Category:Pneumatic Actuators
Product Lifecycle:Active
Product description
standards-based cylinder DSNU-16-50-PPS-A with self-adjusting pneumatic end position cushioning Stroke: 50 mm, Piston diameter: 16 mm, Piston rod thread: M6, Cushioning: PPS: Self-adjusting pneumatic end-position cushioning, Assembly position: Any
Product Details
- Cushioning Self-adjusting pneumatic end-position cushioning
- Design Piston Cylinder barrel
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Cushioning length 12 mm
- Note on materials RoHS-compliant
- Stroke 50 mm
- Mounting position Any
- Position sensing For proximity sensor
- Operating pressure 0.1 MPa ... 1 MPa
- Impact energy in the end positions 0.15 J
- Theoretical force at 6 bar, retracting 103.7 N
- Seals material NBR TPE-U(PU)
- Maritime classification See certificate
- Type code DSNU
- Variants Piston rod at one end
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Basic weight with 0 mm stroke 89.9 g
- Additional moving mass per 10 mm stroke 2 g
- Material of cylinder barrel High-alloy stainless steel
- Piston rod thread M6
- Piston rod end External thread
- Mode of operation Double-acting
- Ambient temperature -20 °C ... 80 °C
- Moving mass at 0 mm stroke 23 g
- Additional weight per 10 mm stroke 4.6 g
- Cover material Wrought aluminum alloy Plain anodized
- Piston rod material High-alloy stainless steel
- Piston diameter 16 mm
- Conforms to standard CETOP RP 52 P ISO 6432
- Symbol 00992970
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Theoretical force at 6 bar, advancing 120.6 N
- Type of mounting With accessories
- Pneumatic connection M5
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
