554226 Festo Pneumatic Actuators

554226 on Powermatic Associates
Festo

Part#:554226

Alt. Part#:ADNGF-20-40-P-A

Manufacturer:Festo

Category:Pneumatic Actuators

Product Lifecycle:Active

Only 1 left in stock. Order Now!

Apr 22, 2025

Product description

compact cylinder ADNGF-20-40-P-A According to ISO 21287, with plain-bearing guide, piston rod secured against rotation by means of guide rods and yoke plate. Stroke: 40 mm, Piston diameter: 20 mm, Based on the standard: ISO 21287, Cushioning: P: Flexible

Product Details

  • Based on norm
    ISO 21287
  • Mode of operation
    Double-acting
  • Moving mass at 0 mm stroke
    60 g
  • Basic weight with 0 mm stroke
    161 g
  • Seals material
    TPE-U(PUR)
  • Piston diameter
    20 mm
  • Position sensing
    For proximity sensor
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Theoretical force at 6 bar, advancing
    188 N
  • Pneumatic connection
    M5
  • Piston rod material
    High-alloy steel
  • Stroke
    40 mm
  • Mounting position
    Any
  • Design
    Piston Profile barrel
  • Ambient temperature
    -20 °C ... 80 °C
  • Theoretical force at 6 bar, retracting
    141 N
  • Note on materials
    RoHS-compliant
  • Cushioning
    Elastic cushioning rings/pads at both ends
  • Protection against torsion/guide
    Guide rod with yoke
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Additional weight per 10 mm stroke
    26 g
  • Cover material
    Aluminum Anodized
  • Type code
    ADNGF
  • Operating pressure
    0.15 MPa ... 1 MPa
  • Impact energy in the end positions
    0.2 J
  • Additional moving mass per 10 mm stroke
    11 g
  • Material of cylinder barrel
    Wrought aluminum alloy Smooth anodized

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
