531680 Festo Pneumatic Fittings
Part#:531680
Alt. Part#:KS4-1/2-I
Manufacturer:Festo
Category:Pneumatic Fittings
Product Lifecycle:Active
Product description
quick coupling plug KS4-1/2-I For self-closing quick coupling connectors. Nominal size: 7,85 mm, Operating pressure complete temperature range: -0,95 - 12 bar, Standard nominal flow rate: 1305 l/min, Operating medium: Compressed air in accordance with ISO
Product Details
- Information on operating and pilot media Operation with oil lubrication possible
- Nominal width 7.85 mm
- Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-]
- Tolerance for nominal tightening torque ± 20%
- Type code KS4
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Product weight 57 g
- Operating pressure for entire temperature range -0.95 bar ... 12 bar
- Nominal tightening torque 32.5 Nm
- Pneumatic connection 1 Internal thread G1/2
- Standard nominal flow rate 1305 l/min
- Ambient temperature -10 °C ... 60 °C
- Note on materials RoHS-compliant
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
