525234 Festo Pneumatic Valves Accessories

525234 on Powermatic Associates
Festo

Part#:525234

Alt. Part#:MHA4-PR2-3-1/4

Manufacturer:Festo

Category:Pneumatic Valves Accessories

Product Lifecycle:Active

Product description

manifold block MHA4-PR2-3-1/4 For sub-base valves MHA4-... Max. number of valve positions: 2, Corrosion resistance classification CRC: 2 - Moderate corrosion stress, Product weight: 440 g, Mounting method for sub-base: (* with through hole, * with top-hat

Product Details

  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Sub-base mounting type
    With through-hole With H-rail
  • Material of sub-base
    Wrought aluminum alloy
  • Type code
    MH4
  • Pneumatic valve mounting type
    With internal thread
  • Pneumatic connection 3/11
    G3/8
  • Pneumatic connection 1/33
    G3/8
  • Max. no. of valve positions
    2
  • Note on materials
    Free of copper and PTFE
  • Product weight
    440 g
  • Pneumatic connection 2
    Internal thread G1/4

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
