3612 Festo Pneumatic Fittings

3612 on Powermatic Associates
Festo

Part#:3612

Alt. Part#:N-3/4-P-13

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

Product description

barbed hose fitting N-3/4-P-13 With sealing ring. Nominal size: 11 mm, Type of seal on screw-in stud: Sealing ring, Operating pressure complete temperature range: -0,95 - 16 bar, Operating medium: Compressed air in accordance with ISO8573-1:2010 [7:-:-],

Product Details

  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Type code
    N
  • Pneumatic connection 2
    for pneumatic tubing inside diameter 13 mm
  • Type of seal on screwed trunnion
    Sealing ring
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Nominal width
    11 mm
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Operating pressure for entire temperature range
    -0.95 bar ... 16 bar
  • Note on materials
    RoHS-compliant
  • Pneumatic connection 1
    External thread G3/4

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
