2153 Festo Pneumatic Fittings

2153 on Powermatic Associates
Festo

Part#:2153

Alt. Part#:KS4-N-9

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

Product description

quick coupling plug KS4-N-9 For self-closing quick coupling connectors. Nominal size: 7 mm, Operating pressure complete temperature range: -0,95 - 12 bar, Standard nominal flow rate: 1008 l/min, Operating medium: Compressed air in accordance with ISO8573-

Product Details

  • Standard nominal flow rate
    1008 l/min
  • Nominal width
    7 mm
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Type code
    KS4
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Product weight
    18 g
  • Note on materials
    RoHS-compliant
  • Operating pressure for entire temperature range
    -0.95 bar ... 12 bar
  • Pneumatic connection 1
    N-9
  • Ambient temperature
    -10 °C ... 60 °C
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

2153 Related Documents

2153 DataSheet.pdf
