191198 Festo Actuator Accessories

191198 on Powermatic Associates
Festo

Part#:191198

Alt. Part#:YSRW-20-34

Manufacturer:Festo

Category:Actuator Accessories

Product Lifecycle:Active

Product description

shock absorber YSRW-20-34 Self-adjusting, with progressive characteristic curve. Size: 20, Stroke: 34 mm, Cushioning: (* self-adjusting, * Soft characteristic), Assembly position: Any, Position detection: No

Product Details

  • Type code
    YSRW
  • Reset time at room temperature
    0.3 s
  • Max. energy absorption per hour
    100000 J
  • Seals material
    NBR
  • Mounting position
    Any
  • Reset time at min. ambient temperature
    1 s
  • Ambient temperature
    -10 °C ... 80 °C
  • Max. energy absorption per stroke
    70 J
  • Type of mounting
    With lock nut
  • Piston rod material
    High-alloy steel
  • Size
    20
  • Cushioning
    Self-adjusting Soft characteristic curve
  • Position sensing
    None
  • Max. impact velocity
    3 m/s
  • Max. stop force
    3000 N
  • Resetting force
    10 N
  • Housing material
    Steel Galvanized
  • Stroke
    34 mm
  • Symbol
    00991495
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Max. residual energy
    0.32 J
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Mode of operation
    Single-acting Pushing
  • Cushioning length
    34 mm
  • Product weight
    330 g

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
