191192 Festo Actuator Accessories
Part#:191192
Alt. Part#:YSRW-5-8
Manufacturer:Festo
Category:Actuator Accessories
Product Lifecycle:Active
Product description
shock absorber YSRW-5-8 Self-adjusting, with progressive characteristic curve. Size: 5, Stroke: 8 mm, Cushioning: (* self-adjusting, * Soft characteristic), Assembly position: Any, Position detection: No
Product Details
- Cushioning Self-adjusting Soft characteristic curve
- Reset time at room temperature 0.2 s
- Cushioning length 8 mm
- Max. residual energy 0.01 J
- Seals material NBR
- Stroke 8 mm
- Max. impact velocity 2 m/s
- Reset time at min. ambient temperature 1 s
- Max. energy absorption per hour 10000 J
- Type of mounting With lock nut
- Piston rod material High-alloy steel
- Symbol 00991495
- Mode of operation Single-acting Pushing
- Ambient temperature -10 °C ... 80 °C
- Resetting force 0.9 N
- Housing material High-alloy steel
- Size 5
- Position sensing None
- Max. stop force 200 N
- Product weight 8 g
- Type code YSRW
- Mounting position Any
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Max. energy absorption per stroke 1.3 J
- Note on materials Free of copper and PTFE RoHS-compliant
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
