191193 Festo Actuator Accessories

191193 on Powermatic Associates
Festo

Part#:191193

Alt. Part#:YSRW-7-10

Manufacturer:Festo

Category:Actuator Accessories

Product Lifecycle:Active

Product description

shock absorber YSRW-7-10 Self-adjusting, with progressive characteristic curve. Size: 7, Stroke: 10 mm, Cushioning: (* self-adjusting, * Soft characteristic), Assembly position: Any, Position detection: No

Product Details

  • Cushioning length
    10 mm
  • Symbol
    00991495
  • Mounting position
    Any
  • Reset time at min. ambient temperature
    1 s
  • Max. residual energy
    0.01 J
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Housing material
    High-alloy steel
  • Position sensing
    None
  • Mode of operation
    Single-acting Pushing
  • Resetting force
    1.2 N
  • Seals material
    NBR
  • Stroke
    10 mm
  • Cushioning
    Self-adjusting Soft characteristic curve
  • Reset time at room temperature
    0.2 s
  • Max. energy absorption per hour
    15000 J
  • Product weight
    18 g
  • Size
    7
  • Type code
    YSRW
  • Max. impact velocity
    3 m/s
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Max. stop force
    300 N
  • Max. energy absorption per stroke
    2.5 J
  • Piston rod material
    High-alloy steel
  • Ambient temperature
    -10 °C ... 80 °C
  • Type of mounting
    With lock nut

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

191193 Related Documents

191193 DataSheet.pdf
