1609969 Festo Pneumatic Components

1609969 on Powermatic Associates
Festo

Part#:1609969

Alt. Part#:VBOH-32-M5

Manufacturer:Festo

Category:Pneumatic Components

Product Lifecycle:Active

Product description

hand slide valve VBOH-32-M5 Valve function: 3/2 bistable, Pneumatic connection, port 1: M5, Pneumatic connection, port 2: M5, Type of actuation: manual, Mounting type: (* Line installation, * Threaded)

Product Details

  • Ambient temperature
    -10 °C ... 80 °C
  • Width dimension
    17 mm
  • Design
    Sleeve gate valve
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Note on materials
    RoHS-compliant
  • Type code
    VBOH
  • Actuation type
    Manual
  • Housing material
    Wrought aluminum alloy Anodized
  • Sealing principle
    Soft
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Product weight
    8 g
  • Pneumatic connection 2
    M5
  • Operating pressure
    -0.95 bar ... 12 bar
  • Mounting position
    Any
  • Actuating force
    14 N
  • Valve function
    3/2, bistable
  • Type of mounting
    Line installation Screw-in
  • Nominal width
    3.6 mm
  • Type of control
    Direct
  • Temperature of medium
    -10 °C ... 80 °C
  • Seals material
    NBR
  • Pneumatic connection 1
    M5
  • Standard nominal flow rate
    236 l/min
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Symbol
    00991286
  • Material of screwed trunnion
    Wrought aluminum alloy Anodized

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
